MACscr Posted January 12, 2017 Posted January 12, 2017 Seems when I upgrade my pcDuino3 Nano (pcDuino3b to be specific) from the Mainline server 4.7.3 using apt-get to the newest of everything, wifi is no longer seen. I have tried following the kernel upgrade guide as listed here: https://www.armbian.com/pcduino3nano/, but that doesn't seem to solve it. The device isn't even seen anymore. I did at one point get an error in dimes about ‘/lib/firmware/rtlwifi/rtl8188eufw.bin' being missing, which was odd because i don't think thats wifi, but replacing that with one i found on the rpi boards didnt help either. Ive been working on this issue for hours. Everything seems to work great as long as i don't upgrade, but I don't really want my armbian devices to be exposed like that. Thanks, Mark
Igor Posted January 12, 2017 Posted January 12, 2017 Error tells you that firmware for the board is missing: apt-get install armbian-firmware if this does not solve, try: apt-get install armbian-firmware-full Reboot at each try.
MACscr Posted January 12, 2017 Author Posted January 12, 2017 No difference unfortunately and something I had already tried. Doesnt appear to be loaded according to lsmod though: root@8track:/lib/firmware# lsmod Module Size Used by evdev 12164 1 sun4i_codec 11391 3 input_leds 2676 0 ir_lirc_codec 5048 0 snd_soc_core 131126 1 sun4i_codec lirc_dev 7589 1 ir_lirc_codec snd_pcm_dmaengine 3455 1 snd_soc_core snd_pcm 77587 2 snd_pcm_dmaengine,snd_soc_core sun4i_ts 3990 0 snd_timer 19698 1 snd_pcm snd 47943 3 snd_timer,snd_soc_core,snd_pcm nvmem_sunxi_sid 2159 0 soundcore 922 1 snd nvmem_core 9078 1 nvmem_sunxi_sid sunxi_cir 3735 0 sun4i_ss 16066 0 cpufreq_dt 3432 0 thermal_sys 59134 2 sun4i_ts,cpufreq_dt uio_pdrv_genirq 3164 0 uio 8000 1 uio_pdrv_genirq bonding 105334 0 fuse 83932 1 realtek 2775 0 root@8track:/lib/firmware# root@8track:/lib/firmware# root@8track:/lib/firmware# cd /lib/firmware/rtl rtl_bt/ rtl_nic/ rtlwifi/ root@8track:/lib/firmware# cd /lib/firmware/rtlwifi/ root@8track:/lib/firmware/rtlwifi# ls rtl8188efw.bin rtl8192cfwU_B.bin rtl8192cufw_B.bin rtl8192defw.bin rtl8192eu_nic.bin rtl8712u.bin rtl8723aufw_B_NoBT.bin rtl8723bu_nic.bin rtl8723fw.bin rtl8188eufw.bin rtl8192cfwU.bin rtl8192cufw.bin rtl8192eefw.bin rtl8192eu_wowlan.bin rtl8723aufw_A.bin rtl8723befw.bin rtl8723bu_wowlan.bin rtl8821aefw.bin rtl8192cfw.bin rtl8192cufw_A.bin rtl8192cufw_TMSC.bin rtl8192eu_ap_wowlan.bin rtl8192sefw.bin rtl8723aufw_B.bin rtl8723bu_ap_wowlan.bin rtl8723fw_B.bin rtl8821aefw_wowlan.bin root@8track:/lib/firmware/rtlwifi#
Igor Posted January 12, 2017 Posted January 12, 2017 So what you are saying is, that it's working on stock 4.7.3 and it fails to work when you do apt-get upgrade?Can you provide: armbianmonitor -u
MACscr Posted January 12, 2017 Author Posted January 12, 2017 So what you are saying is, that it's working on stock 4.7.3 and it fails to work when you do apt-get upgrade? Can you provide: armbianmonitor -u That is correct. Here are the results you asked for: /var/log/armhwinfo.log has been uploaded to http://sprunge.us/QeQh
Igor Posted January 12, 2017 Posted January 12, 2017 Nothing suspicious in the log except your wifi is not detected. Since we don't maintain this, I don't know the reason - perhaps some regression in driver? Try 3rd party: https://docs.armbian.com/User-Guide_Advanced-Features/#how-to-build-a-wireless-driver
MACscr Posted January 12, 2017 Author Posted January 12, 2017 Nothing suspicious in the log except your wifi is not detected. Since we don't maintain this, I don't know the reason - perhaps some regression in driver? Try 3rd party: https://docs.armbian.com/User-Guide_Advanced-Features/#how-to-build-a-wireless-driver im confused. what do you not maintain? I thought you supported the pcDuino3 Nano
Igor Posted January 12, 2017 Posted January 12, 2017 Sure we do support those boards (free / donation pledge), but not all possible 3rd party USB WiFi sticks. Even onboard adaptors is hard enough. Your board come without wireless ... This is general Linux problem and I am only trying to help the best way I can.
MACscr Posted January 12, 2017 Author Posted January 12, 2017 Sure we do support those boards (free / donation pledge), but not all possible 3rd party USB WiFi sticks. Even onboard adaptors is hard enough. This is general Linux problem and I am only trying to the best way I can. No problem. I understand. This is though the onboard wifi I am talking about. I have no third party hardware connected to this board besides a keyboard and monitor.
Igor Posted January 12, 2017 Posted January 12, 2017 I am not very familiar with this board and out of logs I can see that wireless is connected to USB, which is unusual. No problem about that ... Regarding ID it should be RTL8188CUS which is supported by the 8192cu driver. Why it's not recognised by the driver is hard to say but the most easy way is to try to compile your own, like suggested in one of my previous post. Next is to go deep into the driver, to understand what's going on ... I have some of those adaptors to check up. Sometimes only the product id (idProduct 0x8179) is wrong ... Just in case I would try to connect it via powered USB hub.
Igor Posted January 12, 2017 Posted January 12, 2017 And one more quick option to try is to upgrade further, to daily auto build. Check download page for more info -> Updating from nightly repository?
MACscr Posted January 12, 2017 Author Posted January 12, 2017 And one more quick option to try is to upgrade further, to daily auto build. Check download page for more info -> Updating from nightly repository? Doesnt exist for the Nano.
MACscr Posted January 12, 2017 Author Posted January 12, 2017 I am not very familiar with this board and out of logs I can see that wireless is connected to USB, which is unusual. No problem about that ... Regarding ID it should be RTL8188CUS which is supported by the 8192cu driver. Why it's not recognised by the driver is hard to say but the most easy way is to try to compile your own, like suggested in one of my previous post. Next is to go deep into the driver, to understand what's going on ... I have some of those adaptors to check up. Sometimes only the product id (idProduct 0x8179) is wrong ... Just in case I would try to connect it via powered USB hub. Its definitely onboard (doesnt mean it doesnt go through usb like a lot of other boards do for some of its onboard hardware). Seems my pcDuino3b is form factor of the pcDuino3, but with the gigabit speeds of the Nano. I had to use the nano to get networking to work.
Igor Posted January 12, 2017 Posted January 12, 2017 Doesn't exist for the Nano. Read again. Upgrade exists (for all boards that we support), image doesn't. 1
