I had no idea that there's an OpiZ3W Just in case, it is nothing at all like the Orange Pi Zero 3, which has a lot in common with the OpiZ2W. Yeely: what are your first impressions about this board? Are there demos for the NPU?

@Nick A My bad, cleaned my build folder and it compiled fine. Still, it is still stuck in the bootloader Bootlog: https://pastebin.com/ckqP10Bb I tried with both of my board with and without emmc installed.

Tomb Raider (2013) Armbian 26.05-trunk (Linux kernel 7.0.10-edge-rockchip64) + Panvk: Mesa 26.2.0-devel (git-3df406633e) + DXVK 2.7.1-stripped (https://github.com/khanh-it/dxvk/releases) + Wine: wine-11.9-staging-tkg-amd64-wow64 (https://github.com/Kron4ek/Wine-Builds/releases) + box64: box64-rk3588_0.4.3+20260529.5b7308f-1 (https://github.com/ryanfortner/box64-debs/) ~30fps@720p (default settings)

Okay I will try that when I get back from work, thanks for your time

Ok thanks my apologies. Oh thanks, I missed that point. This box should've been ewaste long ago I gotbthe bright idea.of using it as a low power 'digital sign' driver for my wife's store . I started with ohub bookworm server for the board. I couldn't get the boot toothpick to read cards or usb. It wasn't until I flashed CoreELEC to a card and was trying to see if it was a distro issue that I realized the box was trying to go into android recovery with the toothpick not looking for boot drives. I put aml_autoscript from the CoreELEC root folder and zipped it then I used android recovery mode to clear the cache and update from card pointing at the zip file. Even though the final output was that it failed it actually loaded CoreELEC autoscript and when I rebooted it read the bootloader on sdcard. After discovering that little nuance I did the same for the flashed Arabian distro but it didn't seem to catch the bootloader on sdcard. I assumed I wasn't getting the right dtd.img copied so I tried the most likely for the chip and when I.asked ai it thought I needed a legacy version. When I throw the CoreELEC in now it still boots from the card. I made the assumption that the modifications to android boot would work accross distros so it didn't seem strange that CoreELEC might boot even if it was the bookworm autoscript being used by android. Thanks for taking the time to reply even though it's the wrong forum and my apologies I should've thought that through. Looking at the hub forum it didn't seem like there was much in the way of replies happening. Cheers

Hello, After more research it seems that despite the Wikipedia screenshot, M2 Ultra & M2 Berry do not really have the same CPU : M2U uses R40 and M2B uses V40 This is most probably why it does not work. After checking watchdog & sysrq, I almost rebooted with : echo 1 > /proc/sys/kernel/sysrq echo b > /proc/sysrq-trigger but still hung in the end. I was about to throw the Banana PI away, and I finally found this website which provides a (very) raw debian image for the M2 Berry, and it works correcty including reboot. Sharing the link in case it helps other people with M2B : https://sd-card-images.johang.se/boards/banana_pi_m2_berry.html Thanks for your help Regards

Hello Aniket, as i mentioned the armbian is not working because of the different DRAM Voltage setting in uboot. The board was running with original debian version from RADXA https://github.com/radxa-build/radxa-cubie-a5e/releases. If you check the log you see the dram voltage settings and training. For me i'm waiting until a board with 2/4GB which hopefully runs with armbian. Rolf

Providing logs with armbianmonitor -u helps with troubleshooting and significantly raises chances that issue gets addressed.

Nick's instructions: You need to add this line to the bottom. "+CONFIG_SPL_IMAGE_TYPE_SUNXI_TOC0=y" and change "@@ -0,0 +1,31 @@" to @@ -0,0 +1,32 @@. ./compile.sh choose "Do not change kernel configuration" choose "Show CSC/WIP/EOS/TVB" choose "I understand and agree" choose "X98H" choose "edge" rest is up to you. Your image should be in output/images directory.

There's been a few changes to make etehrnet work on H6 that broek it for H616/H618 seemingly. Your best course of action for now would be to downgrade to 6.12 and lock the `linux-*` from being upgraded.

Just to let you know usb bug is still present in 7.1 rc3 [ 2.596444] usb 4-1: new full-speed USB device number 2 using ohci-platform [ 2.784449] usb 4-1: device descriptor read/64, error -62 [ 3.076447] usb 4-1: device descriptor read/64, error -62 [ 3.356447] usb 4-1: new full-speed USB device number 3 using ohci-platform [ 3.532450] usb 4-1: device descriptor read/64, error -62 [ 3.824440] usb 4-1: device descriptor read/64, error -62 [ 3.928486] usb usb4-port1: attempt power cycle [ 4.140440] usb 4-1: new full-speed USB device number 4 using ohci-platform [ 4.548447] usb 4-1: device not accepting address 4, error -62 [ 4.732456] usb 4-1: new full-speed USB device number 5 using ohci-platform [ 5.140438] usb 4-1: device not accepting address 5, error -62 [ 5.140481] usb usb4-port1: unable to enumerate USB device

Hi everyone, I've just released v1.0.11 of rockchip-vaapi, a VA-API driver for the RK3588 that bridges libva to Rockchip MPP for hardware video decode in Firefox and other VA-API applications. **GitHub:** https://github.com/woodyst/rockchip-vaapi --- ## What it does Enables hardware VP9 / H.264 / HEVC / VP8 decode in Firefox via VA-API → MPP → RK3588 VPU. DMA-BUF zero-copy display path. Tested on Orange Pi 5 Plus with Armbian and Firefox 128. --- ## What's new in v1.0.11 Previous versions would fall back to software after a few seconds of 4K content. This release fixes that — **4K@60fps is now stable**: - **4K@60fps stable** — tested >30,000 frames in Firefox with clean DASH quality switches and no `NS_ERROR_DOM_MEDIA_FATAL_ERR` - **Async EndPicture** — the driver was blocking Firefox's decode thread for up to 1.6s on each DASH segment keyframe, freezing the pipeline. EndPicture now returns immediately. - **Race condition fix** — Firefox was getting a stale DMA-BUF before the decoded frame was ready, causing a green bar at the top of the screen. - **Logging off by default** — ~500 fprintf/s were silently slowing down 60fps decode. Enable with `RK_VAAPI_LOG=/tmp/rk.log` when needed. - **`mpv --vo=dmabuf-wayland`** — green screen fixed (COMPOSED_LAYERS export format) - **`mpv --hwdec=vaapi-copy`** — green screen fixed (GetImage was a stub) - **CMA requirement documented** — 4K needs `cma=512M`; includes `fdtput` fix for boards where the DTB overrides the kernel cmdline --- ## System requirements - **CMA ≥ 512MB** — critical for 4K. Add `cma=512M` to your kernel cmdline. If it has no effect (DTB overrides it), see the `fdtput` fix in INSTALL.md. - librockchip-mpp, libva2 - Firefox: `media.ffmpeg.vaapi.enabled = true` and `MOZ_DISABLE_RDD_SANDBOX=1` --- ## Quick install ```bash git clone https://github.com/woodyst/rockchip-vaapi cd rockchip-vaapi make sudo make install ``` Then launch Firefox: ```bash LIBVA_DRIVER_NAME=rockchip MOZ_DISABLE_RDD_SANDBOX=1 firefox ``` Full instructions: https://github.com/woodyst/rockchip-vaapi/blob/main/INSTALL.md --- Feedback and bug reports welcome.

The short-circuit you did probably created feedback loop generating tension coming back to some component of the board, possibly burning it unfortunately. Never join 2 power sources without filter balancing it or adding extra capacitors... Is the board turning on? Try to turn on and look for heated places in the board... With a thermal camera will be easier, but if you don't have one, you may touch the components to see which are hot, or add some drops of isopropyl alcohol only on top of components and see if it evaporates too fast like this -> link. If a component is heating too fast, probably its short-circuited/burnt and needs replacement.

Hi! I've been using this Armbian image on my H96 RK3566 for small projects. Thanks a lot for releasing it! Right now, I need to use the NPU for a small AI project. I know it's possible to activate it, but it doesn't look easy. I've read that there is NPU support on legacy kernels (v5.10/v5.15), but I haven't been able to find that specific version for the H96 RK3566. My question is: how difficult would it be to add or backport this NPU module to the current mainline kernel version?

Fixing is on the way https://github.com/armbian/build/pull/9908, after merging, i generate new images.

I fried SOIC-8 IC (Probably power management) on H96 Max X2 PCB (I-BOX TV) by applying 12V If anyone (@Thang?) has a board like that, please take a close up of that chip on the back side. I might be able to source it and replace it. Original related topic by Thang is here. BTW, there is native console available on pretty much all Armbian boards, that lets you see linux messages before they appear on the HDMI port. It helps to understand the bootloader sequence, u-boot sequence and gives you root access.

Hi @Jean-Francois Lessard Thanks for sharing the new openvfd option for Armbian. I am using a Allwinner H618 Android 12 TV box that got FD6551 controller. I have verified the chip model by opening the box. The headers of respective version is also installed and I have double checked that. apt install -y linux-headers-edge-sunxi64 Reading package lists... Done Building dependency tree... Done Reading state information... Done linux-headers-edge-sunxi64 is already the newest version (25.11.2). From the Android dts file I can find the following. I have tried the configuration mentioned here as well but there is no VFD output. Is there any other configuration I have to check or modify for the VFD to work? leds { leds_clk = <0x23 0x08 0x0b 0x00>; leds_dat = <0x23 0x08 0x0c 0x00>; status = "okay"; }; fd655_para { device_type = "fd655_para"; compatible = "Ik,fd655_dev"; fd655_clk_io = <0x23 0x07 0x06 0x01>; fd655_dat_io = <0x23 0x07 0x07 0x01>; status = "okay"; }; ald-colorleds { compatible = "elebao,colorleds"; dev_name = "ald-colorleds"; pinctrl-0 = <0x70>; colorleds_data_gpio = <0x23 0x07 0x02 0x01>; status = "okay"; }; I tried to make the module as you have instructed, however I am getting the below given error messages. /tm16xx-display# make module make EXTRA_CFLAGS="-DCONFIG_TM16XX -DCONFIG_TM16XX_KEYPAD -DCONFIG_TM16XX_I2C -DCONFIG_TM16XX_SPI -include /root/tm16xx-display/drivers/auxdisplay/tm16xx_compat.h -I/root/tm16xx-display/include/" -C /lib/modules/6.12.11-edge-sunxi64/build M=/root/tm16xx-display/drivers/auxdisplay CONFIG_TM16XX=m CONFIG_TM16XX_KEYPAD=y CONFIG_TM16XX_I2C=m CONFIG_TM16XX_SPI=m CONFIG_LINEDISP=m modules make[1]: Entering directory '/usr/src/linux-headers-6.12.11-edge-sunxi64' CC [M] /root/tm16xx-display/drivers/auxdisplay/line-display.o CC [M] /root/tm16xx-display/drivers/auxdisplay/tm16xx_core.o CC [M] /root/tm16xx-display/drivers/auxdisplay/tm16xx_keypad.o LD [M] /root/tm16xx-display/drivers/auxdisplay/tm16xx.o CC [M] /root/tm16xx-display/drivers/auxdisplay/tm16xx_i2c.o CC [M] /root/tm16xx-display/drivers/auxdisplay/tm16xx_spi.o MODPOST /root/tm16xx-display/drivers/auxdisplay/Module.symvers CC [M] /root/tm16xx-display/drivers/auxdisplay/line-display.mod.o In file included from /root/tm16xx-display/drivers/auxdisplay/line-display.mod.c:2: /root/tm16xx-display/drivers/auxdisplay/line-display.mod.c:13:41: error: expected ‘)’ before ‘LINEDISP’ 13 | KSYMTAB_FUNC(linedisp_attach, "_gpl", ""LINEDISP""); | ^~~~~~~~ ./include/linux/export-internal.h:45:28: note: in definition of macro ‘__KSYMTAB’ 45 | " .asciz \"" ns "\"" "\n" \ | ^~ /root/tm16xx-display/drivers/auxdisplay/line-display.mod.c:13:1: note: in expansion of macro ‘KSYMTAB_FUNC’ 13 | KSYMTAB_FUNC(linedisp_attach, "_gpl", ""LINEDISP""); | ^~~~~~~~~~~~ ./include/linux/export-internal.h:41:12: note: to match this ‘(’ 41 | asm(" .section \"__ksymtab_strings\",\"aMS\",%progbits,1" "\n" \ | ^ ./include/linux/export-internal.h:62:41: note: in expansion of macro ‘__KSYMTAB’ 62 | #define KSYMTAB_FUNC(name, sec, ns) __KSYMTAB(name, KSYM_FUNC(name), sec, ns) | ^~~~~~~~~ /root/tm16xx-display/drivers/auxdisplay/line-display.mod.c:13:1: note: in expansion of macro ‘KSYMTAB_FUNC’ 13 | KSYMTAB_FUNC(linedisp_attach, "_gpl", ""LINEDISP""); | ^~~~~~~~~~~~ /root/tm16xx-display/drivers/auxdisplay/line-display.mod.c:14:41: error: expected ‘)’ before ‘LINEDISP’ 14 | KSYMTAB_FUNC(linedisp_detach, "_gpl", ""LINEDISP""); | ^~~~~~~~ ./include/linux/export-internal.h:45:28: note: in definition of macro ‘__KSYMTAB’ 45 | " .asciz \"" ns "\"" "\n" \ | ^~ /root/tm16xx-display/drivers/auxdisplay/line-display.mod.c:14:1: note: in expansion of macro ‘KSYMTAB_FUNC’ 14 | KSYMTAB_FUNC(linedisp_detach, "_gpl", ""LINEDISP""); | ^~~~~~~~~~~~ ./include/linux/export-internal.h:41:12: note: to match this ‘(’ 41 | asm(" .section \"__ksymtab_strings\",\"aMS\",%progbits,1" "\n" \ | ^ ./include/linux/export-internal.h:62:41: note: in expansion of macro ‘__KSYMTAB’ 62 | #define KSYMTAB_FUNC(name, sec, ns) __KSYMTAB(name, KSYM_FUNC(name), sec, ns) | ^~~~~~~~~ /root/tm16xx-display/drivers/auxdisplay/line-display.mod.c:14:1: note: in expansion of macro ‘KSYMTAB_FUNC’ 14 | KSYMTAB_FUNC(linedisp_detach, "_gpl", ""LINEDISP""); | ^~~~~~~~~~~~ /root/tm16xx-display/drivers/auxdisplay/line-display.mod.c:15:43: error: expected ‘)’ before ‘LINEDISP’ 15 | KSYMTAB_FUNC(linedisp_register, "_gpl", ""LINEDISP""); | ^~~~~~~~ ./include/linux/export-internal.h:45:28: note: in definition of macro ‘__KSYMTAB’ 45 | " .asciz \"" ns "\"" "\n" \ | ^~ /root/tm16xx-display/drivers/auxdisplay/line-display.mod.c:15:1: note: in expansion of macro ‘KSYMTAB_FUNC’ 15 | KSYMTAB_FUNC(linedisp_register, "_gpl", ""LINEDISP""); | ^~~~~~~~~~~~ ./include/linux/export-internal.h:41:12: note: to match this ‘(’ 41 | asm(" .section \"__ksymtab_strings\",\"aMS\",%progbits,1" "\n" \ | ^ ./include/linux/export-internal.h:62:41: note: in expansion of macro ‘__KSYMTAB’ 62 | #define KSYMTAB_FUNC(name, sec, ns) __KSYMTAB(name, KSYM_FUNC(name), sec, ns) | ^~~~~~~~~ /root/tm16xx-display/drivers/auxdisplay/line-display.mod.c:15:1: note: in expansion of macro ‘KSYMTAB_FUNC’ 15 | KSYMTAB_FUNC(linedisp_register, "_gpl", ""LINEDISP""); | ^~~~~~~~~~~~ /root/tm16xx-display/drivers/auxdisplay/line-display.mod.c:16:45: error: expected ‘)’ before ‘LINEDISP’ 16 | KSYMTAB_FUNC(linedisp_unregister, "_gpl", ""LINEDISP""); | ^~~~~~~~ ./include/linux/export-internal.h:45:28: note: in definition of macro ‘__KSYMTAB’ 45 | " .asciz \"" ns "\"" "\n" \ | ^~ /root/tm16xx-display/drivers/auxdisplay/line-display.mod.c:16:1: note: in expansion of macro ‘KSYMTAB_FUNC’ 16 | KSYMTAB_FUNC(linedisp_unregister, "_gpl", ""LINEDISP""); | ^~~~~~~~~~~~ ./include/linux/export-internal.h:41:12: note: to match this ‘(’ 41 | asm(" .section \"__ksymtab_strings\",\"aMS\",%progbits,1" "\n" \ | ^ ./include/linux/export-internal.h:62:41: note: in expansion of macro ‘__KSYMTAB’ 62 | #define KSYMTAB_FUNC(name, sec, ns) __KSYMTAB(name, KSYM_FUNC(name), sec, ns) | ^~~~~~~~~ /root/tm16xx-display/drivers/auxdisplay/line-display.mod.c:16:1: note: in expansion of macro ‘KSYMTAB_FUNC’ 16 | KSYMTAB_FUNC(linedisp_unregister, "_gpl", ""LINEDISP""); | ^~~~~~~~~~~~ make[3]: *** [scripts/Makefile.modfinal:31: /root/tm16xx-display/drivers/auxdisplay/line-display.mod.o] Error 1 make[2]: *** [/usr/src/linux-headers-6.12.11-edge-sunxi64/Makefile:1870: modules] Error 2 make[1]: *** [Makefile:224: __sub-make] Error 2 make[1]: Leaving directory '/usr/src/linux-headers-6.12.11-edge-sunxi64' make: *** [Makefile:50: module] Error 2 root@homeassistant2:~/tm16xx-display# make-module install make-module: command not found root@homeassistant2:~/tm16xx-display# make module-install make -C /lib/modules/6.12.11-edge-sunxi64/build M=/root/tm16xx-display/drivers/auxdisplay CONFIG_TM16XX=m CONFIG_TM16XX_KEYPAD=y CONFIG_TM16XX_I2C=m CONFIG_TM16XX_SPI=m CONFIG_LINEDISP=m modules_install INSTALL_MOD_PATH= make[1]: Entering directory '/usr/src/linux-headers-6.12.11-edge-sunxi64' DEPMOD /lib/modules/6.12.11-edge-sunxi64 Warning: modules_install: missing 'System.map' file. Skipping depmod. make[1]: Leaving directory '/usr/src/linux-headers-6.12.11-edge-sunxi64' root@homeassistant2:~/tm16xx-display# make service-install modprobe tm16xx modprobe: ERROR: could not insert 'tm16xx': Exec format error make: *** [Makefile:60: service-install] Error 1

Armbian's next release boots the FriendlyElec NanoPi M5 end-to-end from UFS on a mainline U-Boot, with no proprietary recovery image in the loop. It is the first RK3576 board in the catalogue to reach this state, and the integration pattern paves the way for the others. UFS, the storage class that replaced eMMC in phones, is packet-based and full-duplex with command queuing. The practical gain over an SD card shows up in random I/O, in latency under concurrent load, and in write endurance that holds up over years of deployment. FriendlyElec ships UFS on the M5 because the RK3576 has a native UFS controller, a sensible choice for any board destined for kiosks, robots, or industrial gateways. What mainline was missingThe UFS controller IP itself had a partial driver in mainline U-Boot. Everything around it was not wired: PHY init sequencing, the regulator rails the device needs before it responds, the device-tree glue that tells U-Boot "yes, this board has UFS." For the M5, none of it existed. There is also a cosmetic detail that catches every newcomer, namely that Rockchip's loader tooling labels UFS as SATA in the RKDevTool storage dropdown. Flashing goes through upgrade_tool, not the more familiar rkdeveloptool, because rkdeveloptool has never had UFS support. How it came togetherThree workstreams had to converge. Jonas Karlman's kwiboo/rk3576 branch carried the upstream RK3576 U-Boot enablement, pinctrl, clocks, storage controller bindings, and has been merging into mainline through 2026. The rockchip-linux/rkbin tree had to ship a UFS-capable MiniLoader, which the RK3576MINIALL.ini recipe assembles from the DDR init, the UFS-aware loader, and the OP-TEE/ATF blobs. The Armbian side was the integration: a board config on U-Boot v2026.04, a U-Boot DT overlay that brings the UFS regulators and PHY up at the right moment, and a flashing path that upgrade_tool accepts. None of these were individually hard. Making them line up is what took the time. On the device, the stack does its job cleanly. The BootROM reads the IDB off UFS and pulls in the TPL; the TPL initialises DDR and the UFS host controller, sequences the regulators, negotiates the link, and reads the next stage; ATF jumps to U-Boot; U-Boot enumerates ufs 0 and loads the kernel; the kernel re-probes the same controller it just booted through. The work, almost all of it, lived at the TPL stage. Controller fine, PHY fine, but the device sits silent if regulator sequencing is wrong by a handful of milliseconds. Once that is right, the upper layers see a clean SCSI-shaped block device and the rest is unsurprising. What it leaves us withFor users with a UFS-equipped M5, the next release image flashes through the FriendlyElec Rockchip workflow with upgrade_tool, BOOT switch on UFS/SD, storage dropdown labelled "SATA". The board boots without an SD card or eMMC involvement, and armbian-install writes the same image to UFS in place once the system is running from another medium. Against microSD on the same hardware the difference is felt rather than benchmarked: small reads land faster, the system stays responsive under concurrent I/O, and the write endurance is in a different ballpark. A few rough edges remain. The vendor tooling will keep calling UFS "SATA" until either Rockchip relabels the GUI or rkdeveloptool grows a cs ufs opcode, neither on the immediate horizon. The BOOT switch is a hardware gate with no software override. And upgrade_tool ships only as a Linux x86_64 ELF, so flashing from an Apple Silicon Mac means a Linux VM with USB passthrough or a Windows host running the GUI. The same plumbing now unlocks every other UFS-equipped RK3576 board in the catalogue. The M5 reached the line first because the hardware was available and the upstream pieces were the most complete. The others should be substantially less work, now that the integration pattern exists and the loader path has been proven on real silicon. View the full article

Armbian's next release boots the FriendlyElec NanoPi M5 end-to-end from UFS on a mainline U-Boot, with no proprietary recovery image in the loop. It is the first RK3576 board in the catalogue to reach this state, and the integration pattern paves the way for the others. UFS, the storage class that replaced eMMC in phones, is packet-based and full-duplex with command queuing. The practical gain over an SD card shows up in random I/O, in latency under concurrent load, and in write endurance that holds up over years of deployment. FriendlyElec ships UFS on the M5 because the RK3576 has a native UFS controller, a sensible choice for any board destined for kiosks, robots, or industrial gateways. What mainline was missingThe UFS controller IP itself had a partial driver in mainline U-Boot. Everything around it was not wired: PHY init sequencing, the regulator rails the device needs before it responds, the device-tree glue that tells U-Boot "yes, this board has UFS." For the M5, none of it existed. There is also a cosmetic detail that catches every newcomer, namely that Rockchip's loader tooling labels UFS as SATA in the RKDevTool storage dropdown. Flashing goes through upgrade_tool, not the more familiar rkdeveloptool, because rkdeveloptool has never had UFS support. How it came togetherThree workstreams had to converge. Jonas Karlman's kwiboo/rk3576 branch carried the upstream RK3576 U-Boot enablement, pinctrl, clocks, storage controller bindings, and has been merging into mainline through 2026. The rockchip-linux/rkbin tree had to ship a UFS-capable MiniLoader, which the RK3576MINIALL.ini recipe assembles from the DDR init, the UFS-aware loader, and the OP-TEE/ATF blobs. The Armbian side was the integration: a board config on U-Boot v2026.04, a U-Boot DT overlay that brings the UFS regulators and PHY up at the right moment, and a flashing path that upgrade_tool accepts. None of these were individually hard. Making them line up is what took the time. On the device, the stack does its job cleanly. The BootROM reads the IDB off UFS and pulls in the TPL; the TPL initialises DDR and the UFS host controller, sequences the regulators, negotiates the link, and reads the next stage; ATF jumps to U-Boot; U-Boot enumerates ufs 0 and loads the kernel; the kernel re-probes the same controller it just booted through. The work, almost all of it, lived at the TPL stage. Controller fine, PHY fine, but the device sits silent if regulator sequencing is wrong by a handful of milliseconds. Once that is right, the upper layers see a clean SCSI-shaped block device and the rest is unsurprising. What it leaves us withFor users with a UFS-equipped M5, the next release image flashes through the FriendlyElec Rockchip workflow with upgrade_tool, BOOT switch on UFS/SD, storage dropdown labelled "SATA". The board boots without an SD card or eMMC involvement, and armbian-install writes the same image to UFS in place once the system is running from another medium. Against microSD on the same hardware the difference is felt rather than benchmarked: small reads land faster, the system stays responsive under concurrent I/O, and the write endurance is in a different ballpark. A few rough edges remain. The vendor tooling will keep calling UFS "SATA" until either Rockchip relabels the GUI or rkdeveloptool grows a cs ufs opcode, neither on the immediate horizon. The BOOT switch is a hardware gate with no software override. And upgrade_tool ships only as a Linux x86_64 ELF, so flashing from an Apple Silicon Mac means a Linux VM with USB passthrough or a Windows host running the GUI. The same plumbing now unlocks every other UFS-equipped RK3576 board in the catalogue. The M5 reached the line first because the hardware was available and the upstream pieces were the most complete. The others should be substantially less work, now that the integration pattern exists and the loader path has been proven on real silicon. View the full article

Board: Orangepi3-lts Images: * Armbian_26.5.1_Orangepi3-lts_trixie_current_6.18.33_minimal.img.xz Passed tests: * SHA-256 passed All below testing done via wired and wireless console connection(headless) * initial setup passed * create main user passed * update/upgrade check as root passed * log in as created user pass * update/upgrade check as the created user passed Result: All tested images do exist, are verified, and work properly

Hi @JamesCL. You cannot change the boot order of the SoC (SD -> eMMC -> MTD / SPI flash), thus i.e. the SD card is always booted if inserted. You can probably change the root file system's UUID, i.e. change the /boot/extlinux/extlinux.conf to give the kernel the command to use eMMC as root file system. HTH // Sven-Ola

Perhaps you can try to build Yamagi from source, as I pointed out, a developer has really optimized OpenGL ES. Here you can see it on a VisionFive 2, RISC-V SBC, hitting almost 200fps at 1080p! You can also try PS1 emulation with PCSXR (works without PS1 BIOS). I assume it's just: sudo apt install rpcsx .If you have a PS1 BIOS, you can also try Duckstation. If you need a game for testing, you can try Magic Castle. It was released for free. http://netyaroze.com/Media/Magic-Castle https://archive.org/details/magic-castle-2021-07-may Regarding eDuke32, did you try disabling compressed textures? https://wiki.eduke32.com/wiki/Frequently_Asked_Questions

I can confirm the 5GHz operation on DQ08 board. Now it's time to have a closer look at the kernel source and the non-matching DTS mess.

@Nick A Thanks for releasing the wonderful Armbian image for the Allwinner H618 and for supporting the community with your valuable suggestions. I recently purchased a TV box with 4GB of RAM and 64GB of storage running Android 12. I downloaded Armbian-unofficial_25.05.0-trunk_Transpeed-8k618-t_bookworm_edge_6.12.11_server.img.xz from here and flashed it to an SD card using BalenaEtcher. The box boots successfully, and I can configure it via the CLI. However, this motherboard is different from the ones previously posted here. The silkscreen on the board reads "X3Plus_H618_4bit_V3.0". Based on the naming convention and the appearance of the device, it seems to be the model available here. This board uses an FD6551 chip for the front VFD display. I have managed to extract .img file from the stock android. Are there any modifications I need to make to get the Wi-Fi, USB ports, and front VFD working? Could you please suggest? Things that are working: HDMI Display LAN Controller 1 out of the 2 USB ports. The port near to SD Card slot more precisely Things that are not working: WiFi - The chip got a metal shield. On top of the shield it is written with W804S1, inside the shield I could find AIC8800D40 chip. 1 x USB Port - Near the top left hand corner Front VFD display.

First of all, spamming balance on an SSD will significantly lower the lifespan of it. What you do is ask btrfs to relocate data-chunks that are occupying the % of a block, so that 1 goes fast is because they are very small (1%), but when you ask it to scan and look for a position to move chunks that occupy +50% it WILL take a long time, a veeeeery long time, not to mention 95%. You are basically just moving around data slowly killing your SSD. Read here: https://btrfs.readthedocs.io/en/latest/Balance.html#compact-under-used-chunks Btrfs will do this automatically in the background constantly when your computer is having extra cycles to do so. The only time it will be useful is if you remove massive amounts of data, then you can notice neither data nor metadata freeing up space. It can also be useful if you are using RAID because then it can move data between the disks. IIRC -susage is irrelevant for most users, what you want to move is the data and metadata, ie -musage & -dusage. If ever run a balance, it's when I remove big, and I mean BIG chunks of data, like 25% of the drive, and when I do, I start with 5, increment by 5 up to 35, NEVER more. But it is ONLY if I actually need the space immediately for something else, otherwise I just wait and let btrfs handle it by itself. So, with what you are doing with your cron running every day is literally killing your ssd... You should probably stop, IMMEDIATELY. With a --full-balance, you rewrite ALL DATA on the ENTIRE DRIVE! Better to have a scrub running once per month or every second week or so to know that your drive is in healthy condition... So what you are experiencing is not a bug, it's how it works, and in worst case scenario it might be your ssd about to give up... This link, albeit reddit describes it pretty good: https://www.reddit.com/r/btrfs/comments/hfpot9/what_does_balance_actually_balance BTW, you can check what it is doing while running by typing: sudo watch -n1 'btrfs balance status /path' But again, I HIGHLY discourage you do balance unless you ABSOLUTELY need to. Edit I missed that the filesystem has become read only when responding to this at 4am so lets edit this with a bit more info. Well, I'm sorry, it looks like you killed your drive, or at least the filesystem. The best you can do is try to copy all files on it to another drive (probably not worth trying to save the filesystem), format this one and pray that it's only your filesystem that became corrupt. But after reading how you treated that drive I think you should be prepared for it being damaged beyond a reformat, or that if you manage to format it, it will become corrupted pretty soon again, so I would not rely on that drive for backups... I have found SMART to not be reliable when it comes to health. If you like btrfs, I would recommend buying a rpi, a 6TB spinning drive, a hd case and run urbackup on that. That is what I use (rpi4 8gb, which is overkill, it never utilizes more than 2-3G memory on it, even though I use it as a backup server, nfs network drive AND is running a plex server on it) and it has been running flawlessly for years. (that reminds me, I might want to install something newer than rpi os bullseye on it, maybe armbian xD) I only make file backups, no images. Not very fast, but what does that matter when you only use it for backups. (I run the NFS network drive from another storage device, but that is beside the point) If you also use btrfs on the system you backup from, it creates a snapshot at runtime that it transfers files from, so there is no risk of corrupting files while the backup is running due to files changing during the backup. You would probably get all that for the same price as one ssd, or at least close to, spinning dives cost close to nothing. I have 5 clients connected to that backup solution, with 4 backups daily saved for about 2,5 months (one backup every 5hrs and backups paused between 3am-7am), and one archived every month to save for three years. ie 240 incremental backups per device. One of the clients backing up 1.13T (the others are smaller, between 100-350G each) but all of it only taking up about 5.5TB, and backups runs fast af, only copying changed data due btrfs and de-duplication (COW). I have NEVER had to run a balance on that device (only done it once before for testing). But since it is getting close to the threshold, let's make an experiment and run a balance on it with chunks up to 30%. There are 987 snapshots on that device (not all 5 clients has reached 240 backups due to not being constantly turned on, my laptop and my installed "fallback" os for example) $ sudo btrfs subvol list /media/backup | wc -l 987 This is before balancing: $ sudo btrfs fi df --si /media/backup Data, single: total=5.60TB, used=5.60TB System, DUP: total=33.55MB, used=606.21kB Metadata, DUP: total=31.14GB, used=27.71GB GlobalReserve, single: total=536.87MB, used=0.00B The balance up to 20% took about 5 seconds, then on 25 and 30 it took a while, about 10 minutes (I forgot to run it with time so this is an estimate with me looking at the clock when starting and when saw it had it ended) It only moved a minimum amount of chunks $ sudo bin/btrfs-balance.sh --backup If balancing takes a long time, open another terminal and run: sudo watch -n1 'btrfs balance status /path' btrfs balance will run on /media/backup Do you want to continue? [y/n] y Dumping filters: flags 0x6, state 0x0, force is off METADATA (flags 0x2): balancing, usage=5 SYSTEM (flags 0x2): balancing, usage=5 Done, had to relocate 1 out of 5253 chunks Dumping filters: flags 0x1, state 0x0, force is off DATA (flags 0x2): balancing, usage=5 Done, had to relocate 0 out of 5253 chunks Dumping filters: flags 0x6, state 0x0, force is off METADATA (flags 0x2): balancing, usage=10 SYSTEM (flags 0x2): balancing, usage=10 Done, had to relocate 1 out of 5253 chunks Dumping filters: flags 0x1, state 0x0, force is off DATA (flags 0x2): balancing, usage=10 Done, had to relocate 0 out of 5253 chunks Dumping filters: flags 0x6, state 0x0, force is off METADATA (flags 0x2): balancing, usage=15 SYSTEM (flags 0x2): balancing, usage=15 Done, had to relocate 1 out of 5253 chunks Dumping filters: flags 0x1, state 0x0, force is off DATA (flags 0x2): balancing, usage=15 Done, had to relocate 0 out of 5253 chunks Dumping filters: flags 0x6, state 0x0, force is off METADATA (flags 0x2): balancing, usage=20 SYSTEM (flags 0x2): balancing, usage=20 Done, had to relocate 1 out of 5253 chunks Dumping filters: flags 0x1, state 0x0, force is off DATA (flags 0x2): balancing, usage=20 Done, had to relocate 0 out of 5253 chunks Dumping filters: flags 0x6, state 0x0, force is off METADATA (flags 0x2): balancing, usage=25 SYSTEM (flags 0x2): balancing, usage=25 Done, had to relocate 1 out of 5253 chunks Dumping filters: flags 0x1, state 0x0, force is off DATA (flags 0x2): balancing, usage=25 Done, had to relocate 1 out of 5253 chunks Dumping filters: flags 0x6, state 0x0, force is off METADATA (flags 0x2): balancing, usage=30 SYSTEM (flags 0x2): balancing, usage=30 Done, had to relocate 1 out of 5252 chunks Dumping filters: flags 0x1, state 0x0, force is off DATA (flags 0x2): balancing, usage=30 Done, had to relocate 0 out of 5252 chunks Dumping filters: flags 0x6, state 0x0, force is off METADATA (flags 0x2): balancing, usage=30 SYSTEM (flags 0x2): balancing, usage=30 Done, had to relocate 1 out of 5252 chunks Dumping filters: flags 0x1, state 0x0, force is off DATA (flags 0x2): balancing, usage=30 Done, had to relocate 0 out of 5252 chunks This is after balancing: $ sudo btrfs fi df --si /media/backup Data, single: total=5.60TB, used=5.60TB System, DUP: total=33.55MB, used=606.21kB Metadata, DUP: total=31.14GB, used=27.71GB GlobalReserve, single: total=536.87MB, used=0.00B As you can see, no change whatsoever because btrfs does this in the background all by itself. And running higher % would not save any space, only take a ton of time, I'm pretty sure of that. If you want the script I used, here you go: (I have two btrfs filesystems on that rpi, modify to your liking if adopting) !/usr/bin/env bash # Check if script is run as root if [ "$EUID" != 0 ]; then echo 'THIS SCRIPT MUST BE RUN AS ROOT! (WITH SUDO)' exit 1 fi if [ "$1" == '--backup' ]; then METHOD='/media/backup' elif [ "$1" == '--usr' ]; then METHOD='/media/usr' else METHOD='all' fi echo 'If balancing takes a long time, open another terminal and run:' echo -e "sudo watch -n1 'btrfs balance status /path'\n" echo "btrfs balance will run on $METHOD" read -p "Do you want to continue? [y/n] " -n 1 -r if ! [[ "$REPLY" =~ ^[Yy]$ ]]; then echo '' echo 'Aborting...' exit 4 fi echo '' if [ "$METHOD" == '/media/usr' ] || [ "$METHOD" == 'all' ]; then btrfs balance start -v -musage=5 /media/usr btrfs balance start -v -dusage=5 /media/usr btrfs balance start -v -musage=10 /media/usr btrfs balance start -v -dusage=10 /media/usr btrfs balance start -v -musage=15 /media/usr btrfs balance start -v -dusage=15 /media/usr btrfs balance start -v -musage=20 /media/usr btrfs balance start -v -dusage=20 /media/usr btrfs balance start -v -musage=25 /media/usr btrfs balance start -v -dusage=25 /media/usr btrfs balance start -v -musage=30 /media/usr btrfs balance start -v -dusage=30 /media/usr btrfs balance start -v -musage=35 /media/usr btrfs balance start -v -dusage=35 /media/usr fi if [ "$METHOD" == '/media/backup' ] || [ "$METHOD" == 'all' ]; then btrfs balance start -v -musage=5 /media/backup btrfs balance start -v -dusage=5 /media/backup btrfs balance start -v -musage=10 /media/backup btrfs balance start -v -dusage=10 /media/backup btrfs balance start -v -musage=15 /media/backup btrfs balance start -v -dusage=15 /media/backup btrfs balance start -v -musage=20 /media/backup btrfs balance start -v -dusage=20 /media/backup btrfs balance start -v -musage=25 /media/backup btrfs balance start -v -dusage=25 /media/backup btrfs balance start -v -musage=30 /media/backup btrfs balance start -v -dusage=30 /media/backup btrfs balance start -v -musage=30 /media/backup btrfs balance start -v -dusage=30 /media/backup fi exit 0 This probably means I should manually remove some snapshots, because I did make a few massive changes that caused a lot of new data to be created, I do NOT want it to become filled. Conclusion: Don't run btrfs balance unless absolutely necessary, especially on SSD:s!
