Hello SteeMan I mean bricking when trying to install the system to EMMC memory My memory is SDINADF4-16G

Alright, partial success rfkill. Hm perhaps wifi trouble?

That fixed the image writing error, and it does boot. However, it also crashes with a kernel panic... radxa-cubie-a5e login: root Password: _ _ _ __ __ _ _ _ /_\ _ _ _ __ | |__(_)__ _ _ _ ___ _ _ _ _ ___ / _|/ _(_)__(_)__ _| | / _ \| '_| ' \| '_ \ / _` | ' \___| || | ' \/ _ \ _| _| / _| / _` | | /_/ \_\_| |_|_|_|_.__/_\__,_|_||_| \_,_|_||_\___/_| |_| |_\__|_\__,_|_| v26.02 rolling for radxa cubie a5e running Armbian Linux 6.18.2-edge-sunxi64 Packages: Debian stable (trixie) Support: DIY (custom image) IPv4: (LAN) 192.168.1.29 (WAN) 75.159.194.201 IPv6: 2001:56a:7490:ce00:1010:b0ff:fe32:6e82 (WAN) 2001:56a:7490:ce00:50a4:a426:bd37:13c8 Performance: Load: 14% Uptime: 3 minutes Memory usage: 7% of 1.93G CPU temp: 39°C Usage of /: 3% of 58G Commands: Configuration : armbian-config Monitoring : htop root@radxa-cubie-a5e:~# lsblk NAME MAJ:MIN RM SIZE RO TYPE MOUNTPOINTS mmcblk0 179:0 0 59.5G 0 disk ������mmcblk0p1 179:1 0 512M 0 part /boot ������mmcblk0p2 179:2 0 58.4G 0 part /var/log.hdd / zram0 254:0 0 989.2M 0 disk [SWAP] zram1 254:1 0 50M 0 disk /var/log zram2 254:2 0 0B 0 disk root@radxa-cubie-a5e:~# INFO: task rfkill:1190 blocked for more than 120 seconds. Tainted: G O 6.18.2-edge-sunxi64 #17 "echo 0 > /proc/sys/kernel/hung_task_timeout_secs" disables this message. task:rfkill state:D stack:0 pid:1190 tgid:1190 ppid:1 task_flags:0x400100 flags:0x00000019 Call trace: __switch_to+0xcc/0x178 (T) __schedule+0x328/0x948 schedule+0x30/0x100 schedule_timeout+0xc4/0xd4 wait_for_completion+0x84/0x144 mmc_wait_for_req_done+0x68/0x94 mmc_wait_for_req+0xa4/0xec mmc_wait_for_cmd+0x50/0x6c mmc_io_rw_direct+0x88/0x110 sdio_release_irq+0x6c/0x120 aicbsp_sdio_release+0x28/0x78 [aic8800_bsp] aicbsp_set_subsys+0x264/0x28c [aic8800_bsp] bluetooth_set_power+0x3c/0x70 [aic8800_btlpm] rfkill_set_block+0x8c/0x16c [rfkill] rfkill_fop_write+0x118/0x20c [rfkill] vfs_write+0xbc/0x350 ksys_write+0xc0/0xe0 __arm64_sys_write+0x18/0x20 invoke_syscall.constprop.0+0x4c/0xd8 do_el0_svc+0x3c/0xb8 el0_svc+0x38/0x140 el0t_64_sync_handler+0x98/0xdc el0t_64_sync+0x170/0x174 Kernel panic - not syncing: hung_task: blocked tasks CPU: 5 UID: 0 PID: 60 Comm: khungtaskd Tainted: G O 6.18.2-edge-sunxi64 #17 PREEMPT Tainted: [O]=OOT_MODULE Hardware name: Radxa Cubie A5E (DT) Call trace: show_stack+0x14/0x1c (C) dump_stack_lvl+0x30/0x80 dump_stack+0x14/0x1c vpanic+0x2cc/0x2f8 nmi_panic+0x0/0x5c watchdog+0x274/0x6bc kthread+0x114/0x1cc ret_from_fork+0x10/0x20 SMP: stopping secondary CPUs Kernel Offset: disabled CPU features: 0x080000,00008000,48006281,0400701b Memory Limit: none ---[ end Kernel panic - not syncing: hung_task: blocked tasks ]--- Here's the 1st part of the boot log: U-Boot SPL 2026.01-rc5_armbian-2026.01-rc5-S0f6f-Peafc-He0b4-V2edd-B4d1d-R448a (Dec 30 2025 - 18:27:43 +0000) DRAM: 2048 MiB Trying to boot from MMC1 NOTICE: BL31: v2.13.0(debug):armbian NOTICE: BL31: Built : 17:24:26, Dec 30 2025 NOTICE: BL31: Detected Allwinner A523 SoC (1890) NOTICE: BL31: Found U-Boot DTB at 0xa0ab958, model: Radxa Cubie A5E INFO: Configuring SPC Controller INFO: BL31: Platform setup done INFO: GICv3 without legacy support detected. INFO: ARM GICv3 driver initialized in EL3 INFO: Maximum SPI INTID supported: 287 INFO: BL31: Initializing runtime services INFO: BL31: cortex_a55: CPU workaround for erratum 1530923 was applied INFO: PSCI: Suspend is unavailable INFO: BL31: Preparing for EL3 exit to normal world INFO: Entry point address = 0x4a000000 INFO: SPSR = 0x3c9 ns16550_serial serial@2500000: pinctrl_select_state_full: uclass_get_device_by_phandle_id: err=-19 U-Boot 2026.01-rc5_armbian-2026.01-rc5-S0f6f-Peafc-He0b4-V2edd-B4d1d-R448a (Dec 30 2025 - 18:27:43 +0000) Allwinner Technology CPU: Allwinner A523 (SUN55I) Model: Radxa Cubie A5E DRAM: 2 GiB sunxi_set_gate: (CLK#35) unhandled Core: 77 devices, 22 uclasses, devicetree: separate WDT: Not starting watchdog@2050000 MMC: mmc@4020000: 0 Loading Environment from FAT... Unable to read "uboot.env" from mmc0:1... In: serial@2500000 Out: serial@2500000 Err: serial@2500000 Net: eth0: ethernet@4500000 starting USB... sun4i_usb_phy phy@4100400: External vbus detected, not enabling our own vbus USB EHCI 1.00 USB OHCI 1.0 USB EHCI 1.00 USB OHCI 1.0 Bus usb@4101000: 1 USB Device(s) found Bus usb@4101400: 1 USB Device(s) found Bus usb@4200000: 1 USB Device(s) found Bus usb@4200400: 1 USB Device(s) found scanning usb for storage devices... 0 Storage Device(s) found Hit any key to stop autoboot: 0 switch to partitions #0, OK mmc0 is current device Scanning mmc 0:1... Found U-Boot script /boot.scr 4641 bytes read in 2 ms (2.2 MiB/s) ## Executing script at 4fc00000 U-boot loaded from SD Boot script loaded from mmc 239 bytes read in 1 ms (233.4 KiB/s) Load fdt: /dtb/allwinner/sun55i-a527-cubie-a5e.dtb 33947 bytes read in 6 ms (5.4 MiB/s) Working FDT set to 4fa00000 Failed to load '/dtb/allwinner/overlay/sun55i-a527-fixup.scr' 15461313 bytes read in 642 ms (23 MiB/s) 31652352 bytes read in 1311 ms (23 MiB/s) Moving Image from 0x40080000 to 0x40200000, end=0x42120000 ## Loading init Ramdisk from Legacy Image at 4ff00000 ... Image Name: uInitrd Image Type: AArch64 Linux RAMDisk Image (gzip compressed) Data Size: 15461249 Bytes = 14.7 MiB Load Address: 00000000 Entry Point: 00000000 Verifying Checksum ... OK ## Flattened Device Tree blob at 4fa00000 Booting using the fdt blob at 0x4fa00000 Working FDT set to 4fa00000 Loading Ramdisk to 49141000, end 49fffb81 ... OK Loading Device Tree to 00000000490d0000, end 0000000049140fff ... OK Working FDT set to 490d0000 Starting kernel ... Booting Linux on physical CPU 0x0000000000 [0x412fd050] Linux version 6.18.2-edge-sunxi64 (build@armbian) (aarch64-linux-gnu-gcc (Ubuntu 13.3.0-6ubuntu2~24.04) 13.3.0, GNU ld (GNU Binutils for Ubuntu) 2.42) #17 SMP PREEMPT Thu Dec 18 13:03:43 UTC 2025 KASLR disabled due to lack of seed Machine model: Radxa Cubie A5E efi: UEFI not found. OF: reserved mem: Reserved memory: No reserved-memory node in the DT Zone ranges: DMA [mem 0x0000000040000000-0x00000000bfffffff] DMA32 empty Normal empty Movable zone start for each node Early memory node ranges node 0: [mem 0x0000000040000000-0x00000000bfffffff] Initmem setup node 0 [mem 0x0000000040000000-0x00000000bfffffff] cma: Reserved 64 MiB at 0x00000000b9800000 psci: probing for conduit method from DT. psci: PSCIv1.1 detected in firmware. psci: Using standard PSCI v0.2 function IDs psci: MIGRATE_INFO_TYPE not supported. psci: SMC Calling Convention v1.5 percpu: Embedded 24 pages/cpu s58712 r8192 d31400 u98304 Detected VIPT I-cache on CPU0 CPU features: detected: GICv3 CPU interface CPU features: detected: Virtualization Host Extensions CPU features: detected: ARM errata 1165522, 1319367, or 1530923 alternatives: applying boot alternatives Kernel command line: root=UUID=2782653c-c693-428c-b157-01071e773e18 rootwait rootfstype=ext4 splash=verbose console=ttyS0,115200 console=tty1 consoleblank=0 loglevel=7 ubootpart=3633d9eb-8271-425a-9e37-7ba36a001dbc usb-storage.quirks=0x2537:0x1066:u,0x2537:0x1068:u cgroup_enable=memory Unknown kernel command line parameters "splash=verbose ubootpart=3633d9eb-8271-425a-9e37-7ba36a001dbc cgroup_enable=memory", will be passed to user space. printk: log buffer data + meta data: 131072 + 458752 = 589824 bytes Dentry cache hash table entries: 262144 (order: 9, 2097152 bytes, linear) Inode-cache hash table entries: 131072 (order: 8, 1048576 bytes, linear) software IO TLB: SWIOTLB bounce buffer size adjusted to 2MB software IO TLB: area num 8. software IO TLB: mapped [mem 0x00000000b9600000-0x00000000b9800000] (2MB) Built 1 zonelists, mobility grouping on. Total pages: 524288 mem auto-init: stack:all(zero), heap alloc:off, heap free:off SLUB: HWalign=64, Order=0-3, MinObjects=0, CPUs=8, Nodes=1 rcu: Preemptible hierarchical RCU implementation. Trampoline variant of Tasks RCU enabled. Tracing variant of Tasks RCU enabled. rcu: RCU calculated value of scheduler-enlistment delay is 25 jiffies. RCU Tasks: Setting shift to 3 and lim to 1 rcu_task_cb_adjust=1 rcu_task_cpu_ids=8. RCU Tasks Trace: Setting shift to 3 and lim to 1 rcu_task_cb_adjust=1 rcu_task_cpu_ids=8. NR_IRQS: 64, nr_irqs: 64, preallocated irqs: 0 GIC: enabling workaround for GICv3: non-coherent attribute GICv3: GIC: Using split EOI/Deactivate mode GICv3: 256 SPIs implemented GICv3: 0 Extended SPIs implemented Root IRQ handler: gic_handle_irq GICv3: GICv3 features: 16 PPIs GICv3: GICD_CTLR.DS=0, SCR_EL3.FIQ=0 GICv3: CPU0: found redistributor 0 region 0:0x0000000003460000 ITS [mem 0x03440000-0x0345ffff] GIC: enabling workaround for ITS: non-coherent attribute ITS@0x0000000003440000: allocated 8192 Devices @42470000 (indirect, esz 8, psz 64K, shr 0) ITS@0x0000000003440000: allocated 32768 Interrupt Collections @42480000 (flat, esz 2, psz 64K, shr 0) ITS: using cache flushing for cmd queue GICv3: using LPI property table @0x0000000042490000 GIC: using cache flushing for LPI property table GICv3: CPU0: using allocated LPI pending table @0x00000000424a0000 rcu: srcu_init: Setting srcu_struct sizes based on contention. arch_timer: cp15 timer running at 24.00MHz (phys). clocksource: arch_sys_counter: mask: 0xffffffffffffff max_cycles: 0x588fe9dc0, max_idle_ns: 440795202592 ns sched_clock: 56 bits at 24MHz, resolution 41ns, wraps every 4398046511097ns Console: colour dummy device 80x25 printk: legacy console [tty1] enabled Calibrating delay loop (skipped), value calculated using timer frequency.. 48.00 BogoMIPS (lpj=96000) pid_max: default: 32768 minimum: 301 LSM: initializing lsm=capability,yama,selinux,tomoyo Yama: becoming mindful. SELinux: Initializing. TOMOYO Linux initialized Mount-cache hash table entries: 4096 (order: 3, 32768 bytes, linear) Mountpoint-cache hash table entries: 4096 (order: 3, 32768 bytes, linear) cacheinfo: Unable to detect cache hierarchy for CPU 0 rcu: Hierarchical SRCU implementation. rcu: Max phase no-delay instances is 1000. Timer migration: 1 hierarchy levels; 8 children per group; 1 crossnode level EFI services will not be available. smp: Bringing up secondary CPUs ... Detected VIPT I-cache on CPU1 GICv3: CPU1: found redistributor 100 region 0:0x0000000003480000 GICv3: CPU1: using allocated LPI pending table @0x00000000424b0000 CPU1: Booted secondary processor 0x0000000100 [0x412fd050] Detected VIPT I-cache on CPU2 GICv3: CPU2: found redistributor 200 region 0:0x00000000034a0000 GICv3: CPU2: using allocated LPI pending table @0x00000000424c0000 CPU2: Booted secondary processor 0x0000000200 [0x412fd050] Detected VIPT I-cache on CPU3 GICv3: CPU3: found redistributor 300 region 0:0x00000000034c0000 GICv3: CPU3: using allocated LPI pending table @0x00000000424d0000 CPU3: Booted secondary processor 0x0000000300 [0x412fd050] Detected VIPT I-cache on CPU4 GICv3: CPU4: found redistributor 400 region 0:0x00000000034e0000 GICv3: CPU4: using allocated LPI pending table @0x00000000424e0000 CPU4: Booted secondary processor 0x0000000400 [0x412fd050] Detected VIPT I-cache on CPU5 GICv3: CPU5: found redistributor 500 region 0:0x0000000003500000 GICv3: CPU5: using allocated LPI pending table @0x00000000424f0000 CPU5: Booted secondary processor 0x0000000500 [0x412fd050] Detected VIPT I-cache on CPU6 GICv3: CPU6: found redistributor 600 region 0:0x0000000003520000 GICv3: CPU6: using allocated LPI pending table @0x0000000042500000 CPU6: Booted secondary processor 0x0000000600 [0x412fd050] Detected VIPT I-cache on CPU7 GICv3: CPU7: found redistributor 700 region 0:0x0000000003540000 GICv3: CPU7: using allocated LPI pending table @0x0000000042510000 CPU7: Booted secondary processor 0x0000000700 [0x412fd050] smp: Brought up 1 node, 8 CPUs SMP: Total of 8 processors activated. CPU: All CPU(s) started at EL2 CPU features: detected: 32-bit EL0 Support CPU features: detected: 32-bit EL1 Support CPU features: detected: Data cache clean to the PoU not required for I/D coherence CPU features: detected: Common not Private translations CPU features: detected: CRC32 instructions CPU features: detected: RCpc load-acquire (LDAPR) CPU features: detected: LSE atomic instructions CPU features: detected: Privileged Access Never CPU features: detected: PMUv3 CPU features: detected: Speculative Store Bypassing Safe (SSBS) alternatives: applying system-wide alternatives Memory: 1936768K/2097152K available (15040K kernel code, 1534K rwdata, 10588K rodata, 3584K init, 854K bss, 90016K reserved, 65536K cma-reserved) devtmpfs: initialized clocksource: jiffies: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 7645041785100000 ns posixtimers hash table entries: 4096 (order: 4, 65536 bytes, linear) futex hash table entries: 2048 (131072 bytes on 1 NUMA nodes, total 128 KiB, linear). 24800 pages in range for non-PLT usage 516320 pages in range for PLT usage pinctrl core: initialized pinctrl subsystem DMI not present or invalid. NET: Registered PF_NETLINK/PF_ROUTE protocol family DMA: preallocated 256 KiB GFP_KERNEL pool for atomic allocations DMA: preallocated 256 KiB GFP_KERNEL|GFP_DMA pool for atomic allocations DMA: preallocated 256 KiB GFP_KERNEL|GFP_DMA32 pool for atomic allocations audit: initializing netlink subsys (disabled) audit: type=2000 audit(0.032:1): state=initialized audit_enabled=0 res=1 thermal_sys: Registered thermal governor 'fair_share' thermal_sys: Registered thermal governor 'bang_bang' thermal_sys: Registered thermal governor 'step_wise' thermal_sys: Registered thermal governor 'user_space' cpuidle: using governor ladder cpuidle: using governor menu hw-breakpoint: found 6 breakpoint and 4 watchpoint registers. ASID allocator initialised with 65536 entries /soc/clock-controller@2001000: Fixed dependency cycle(s) with /soc/rtc@7090000 /soc/interrupt-controller@3400000: Fixed dependency cycle(s) with /soc/interrupt-controller@3400000 /soc/clock-controller@7010000: Fixed dependency cycle(s) with /soc/clock-controller@2001000 /soc/clock-controller@7010000: Fixed dependency cycle(s) with /soc/rtc@7090000 /soc/rtc@7090000: Fixed dependency cycle(s) with /soc/clock-controller@7010000 /soc/clock-controller@2001000: Fixed dependency cycle(s) with /soc/rtc@7090000 /soc/clock-controller@7010000: Fixed dependency cycle(s) with /soc/clock-controller@2001000 /soc/clock-controller@7010000: Fixed dependency cycle(s) with /soc/rtc@7090000 /soc/i2c@7081400: Fixed dependency cycle(s) with /soc/pinctrl@7022000/r-i2c-pins /soc/clock-controller@7010000: Fixed dependency cycle(s) with /soc/rtc@7090000 /soc/clock-controller@2001000: Fixed dependency cycle(s) with /soc/rtc@7090000 /soc/rtc@7090000: Fixed dependency cycle(s) with /soc/clock-controller@7010000 raid6: neonx8 gen() 1457 MB/s raid6: neonx4 gen() 1429 MB/s raid6: neonx2 gen() 1399 MB/s raid6: neonx1 gen() 1218 MB/s raid6: int64x8 gen() 911 MB/s raid6: int64x4 gen() 1004 MB/s raid6: int64x2 gen() 959 MB/s raid6: int64x1 gen() 746 MB/s raid6: using algorithm neonx8 gen() 1457 MB/s raid6: .... xor() 1086 MB/s, rmw enabled raid6: using neon recovery algorithm fbcon: Taking over console iommu: Default domain type: Translated iommu: DMA domain TLB invalidation policy: strict mode SCSI subsystem initialized usbcore: registered new interface driver usbfs usbcore: registered new interface driver hub usbcore: registered new device driver usb mc: Linux media interface: v0.10 videodev: Linux video capture interface: v2.00 pps_core: LinuxPPS API ver. 1 registered pps_core: Software ver. 5.3.6 - Copyright 2005-2007 Rodolfo Giometti <giometti@linux.it> PTP clock support registered Advanced Linux Sound Architecture Driver Initialized. NetLabel: Initializing NetLabel: domain hash size = 128 NetLabel: protocols = UNLABELED CIPSOv4 CALIPSO NetLabel: unlabeled traffic allowed by default mctp: management component transport protocol core NET: Registered PF_MCTP protocol family vgaarb: loaded clocksource: Switched to clocksource arch_sys_counter VFS: Disk quotas dquot_6.6.0 VFS: Dquot-cache hash table entries: 512 (order 0, 4096 bytes) netfs: FS-Cache loaded CacheFiles: Loaded NET: Registered PF_INET protocol family IP idents hash table entries: 32768 (order: 6, 262144 bytes, linear) tcp_listen_portaddr_hash hash table entries: 1024 (order: 2, 16384 bytes, linear) Table-perturb hash table entries: 65536 (order: 6, 262144 bytes, linear) TCP established hash table entries: 16384 (order: 5, 131072 bytes, linear) TCP bind hash table entries: 16384 (order: 7, 524288 bytes, linear) TCP: Hash tables configured (established 16384 bind 16384) UDP hash table entries: 1024 (order: 4, 65536 bytes, linear) UDP-Lite hash table entries: 1024 (order: 4, 65536 bytes, linear) NET: Registered PF_UNIX/PF_LOCAL protocol family NET: Registered PF_XDP protocol family PCI: CLS 0 bytes, default 64 Unpacking initramfs... kvm [1]: nv: 568 coarse grained trap handlers kvm [1]: IPA Size Limit: 40 bits kvm [1]: GICv3: no GICV resource entry kvm [1]: disabling GICv2 emulation kvm [1]: GIC system register CPU interface enabled kvm [1]: vgic interrupt IRQ9 kvm [1]: VHE mode initialized successfully Initialise system trusted keyrings workingset: timestamp_bits=46 max_order=19 bucket_order=0 squashfs: version 4.0 (2009/01/31) Phillip Lougher SGI XFS with ACLs, security attributes, scrub, repair, no debug enabled cryptd: max_cpu_qlen set to 1000 NET: Registered PF_ALG protocol family xor: automatically using best checksumming function 32regs Key type asymmetric registered Asymmetric key parser 'x509' registered Asymmetric key parser 'pkcs8' registered Block layer SCSI generic (bsg) driver version 0.4 loaded (major 241) io scheduler mq-deadline registered io scheduler bfq registered ledtrig-cpu: registered to indicate activity on CPUs Serial: 8250/16550 driver, 8 ports, IRQ sharing disabled misc dump reg init loop: module loaded wireguard: WireGuard 1.0.0 loaded. See www.wireguard.com for information. wireguard: Copyright (C) 2015-2019 Jason A. Donenfeld <Jason@zx2c4.com>. All Rights Reserved. tun: Universal TUN/TAP device driver, 1.6 PPP generic driver version 2.4.2 PPP BSD Compression module registered PPP Deflate Compression module registered PPP MPPE Compression module registered NET: Registered PF_PPPOX protocol family usbcore: registered new interface driver usblp usbcore: registered new interface driver usb-storage mousedev: PS/2 mouse device common for all mice sun6i-rtc 7090000.rtc: registered as rtc0 sun6i-rtc 7090000.rtc: setting system clock to 1970-01-02T00:00:07 UTC (86407) i2c_dev: i2c /dev entries driver usbcore: registered new interface driver uvcvideo Driver for 1-wire Dallas network protocol. sunxi-wdt 2050000.watchdog: Watchdog enabled (timeout=16 sec, nowayout=0) SMCCC: SOC_ID: ID = jep106:091e:1890 Revision = 0x00000002 hid: raw HID events driver (C) Jiri Kosina usbcore: registered new interface driver usbhid usbhid: USB HID core driver hw perfevents: enabled with armv8_cortex_a55 PMU driver, 7 (0,8000003f) counters available gnss: GNSS driver registered with major 238 usbcore: registered new interface driver snd-usb-audio NET: Registered PF_INET6 protocol family Segment Routing with IPv6 In-situ OAM (IOAM) with IPv6 NET: Registered PF_PACKET protocol family bridge: filtering via arp/ip/ip6tables is no longer available by default. Update your scripts to load br_netfilter if you need this. 8021q: 802.1Q VLAN Support v1.8 9pnet: Installing 9P2000 support Key type dns_resolver registered registered taskstats version 1 Loading compiled-in X.509 certificates zswap: loaded using pool lzo Key type .fscrypt registered Key type fscrypt-provisioning registered Btrfs loaded, zoned=no, fsverity=no Key type encrypted registered gpio gpiochip0: Static allocation of GPIO base is deprecated, use dynamic allocation. sun55i-a523-r-pinctrl 7022000.pinctrl: initialized sunXi PIO driver sun55i-a523-r-pinctrl 7022000.pinctrl: supply vcc-pl not found, using dummy regulator axp20x-i2c 0-0034: AXP20x variant AXP717 found input: axp20x-pek as /devices/platform/soc/7081400.i2c/i2c-0/0-0034/axp20x-pek/input/input0 platform axp717-adc: DMA mask not set platform axp20x-usb-power-supply: DMA mask not set axp20x-i2c 0-0034: AXP20X driver loaded axp20x-i2c 0-0036: AXP20x variant AXP323 found axp20x-i2c 0-0036: AXP20X driver loaded vcc-mipi-cam: Bringing 2800000uV into 3300000-3300000uV thermal_sys: No trip points found for thermal-sensor id=2 gpio gpiochip1: Static allocation of GPIO base is deprecated, use dynamic allocation. sun55i-a523-pinctrl 2000000.pinctrl: initialized sunXi PIO driver printk: legacy console [ttyS0] disabled 2500000.serial: ttyS0 at MMIO 0x2500000 (irq = 466, base_baud = 1500000) is a 16550A printk: legacy console [ttyS0] enabled Freeing initrd memory: 15096K 2500400.serial: ttyS1 at MMIO 0x2500400 (irq = 467, base_baud = 1500000) is a 16550A dwmac-sun8i 4500000.ethernet: IRQ eth_wake_irq not found dwmac-sun8i 4500000.ethernet: IRQ eth_lpi not found dwmac-sun8i 4500000.ethernet: IRQ sfty not found dwmac-sun8i 4500000.ethernet: supply phy-io not found, using dummy regulator dwmac-sun8i 4500000.ethernet: PTP uses main clock dwmac-sun8i 4500000.ethernet: No HW DMA feature register supported dwmac-sun8i 4500000.ethernet: RX Checksum Offload Engine supported dwmac-sun8i 4500000.ethernet: COE Type 2 dwmac-sun8i 4500000.ethernet: TX Checksum insertion supported dwmac-sun8i 4500000.ethernet: Normal descriptors dwmac-sun8i 4500000.ethernet: Chain mode enabled dwmac-sun55i 4510000.ethernet: IRQ eth_wake_irq not found dwmac-sun55i 4510000.ethernet: IRQ eth_lpi not found dwmac-sun55i 4510000.ethernet: IRQ sfty not found dwmac-sun55i 4510000.ethernet: PTP uses main clock dwmac-sun55i 4510000.ethernet: User ID: 0x20, Synopsys ID: 0x52 dwmac-sun55i 4510000.ethernet: DWMAC4/5 dwmac-sun55i 4510000.ethernet: DMA HW capability register supported dwmac-sun55i 4510000.ethernet: RX Checksum Offload Engine supported dwmac-sun55i 4510000.ethernet: TX Checksum insertion supported dwmac-sun55i 4510000.ethernet: Enable RX Mitigation via HW Watchdog Timer dwmac-sun55i 4510000.ethernet: Enabled RFS Flow TC (entries=10) dwmac-sun55i 4510000.ethernet: Using 32/40 bits DMA host/device width sunxi-mmc 4020000.mmc: Got CD GPIO phy phy-4100400.phy.0: Changing dr_mode to 1 ehci-platform 4200000.usb: EHCI Host Controller ehci-platform 4200000.usb: new USB bus registered, assigned bus number 1 WCN: marlin_init entry! ohci-platform 4200400.usb: Generic Platform OHCI controller ohci-platform 4200400.usb: new USB bus registered, assigned bus number 2 WCN: wcn config bt wake host ehci-platform 4200000.usb: irq 473, io mem 0x04200000 ohci-platform 4200400.usb: irq 475, io mem 0x04200400 WCN_ERR: dts node for bt_wake not found WCN: marlin2 parse_dt some para not config sdiohal:sdiohal_parse_dt adma_tx:1, adma_rx:1, pwrseq:0, irq type:data, gpio_num:0, blksize:840 sdiohal:sdiohal_init ok ohci-platform 4101400.usb: Generic Platform OHCI controller ehci-platform 4101000.usb: EHCI Host Controller ehci-platform 4101000.usb: new USB bus registered, assigned bus number 3 ehci-platform 4101000.usb: irq 472, io mem 0x04101000 WCN: marlin_probe ok! ehci-platform 4200000.usb: USB 2.0 started, EHCI 1.00 usb usb1: New USB device found, idVendor=1d6b, idProduct=0002, bcdDevice= 6.18 usb usb1: New USB device strings: Mfr=3, Product=2, SerialNumber=1 usb usb1: Product: EHCI Host Controller usb usb1: Manufacturer: Linux 6.18.2-edge-sunxi64 ehci_hcd usb usb1: SerialNumber: 4200000.usb hub 1-0:1.0: USB hub found hub 1-0:1.0: 1 port detected ohci-platform 4101400.usb: new USB bus registered, assigned bus number 4 sunxi-mmc 4021000.mmc: initialized, max. request size: 2048 KB, uses new timings mode ehci-platform 4101000.usb: USB 2.0 started, EHCI 1.00 ohci-platform 4101400.usb: irq 474, io mem 0x04101400 sunxi-mmc 4020000.mmc: initialized, max. request size: 2048 KB, uses new timings mode mmc1: new high speed SDIO card at address 390b usb usb3: New USB device found, idVendor=1d6b, idProduct=0002, bcdDevice= 6.18 mmc0: host does not support reading read-only switch, assuming write-enable usb usb3: New USB device strings: Mfr=3, Product=2, SerialNumber=1 mmc0: new high speed SDXC card at address aaaa clk: Disabling unused clocks PM: genpd: Disabling unused power domains ALSA device list: No soundcards found. usb usb3: Product: EHCI Host Controller mmcblk0: mmc0:aaaa SR64G 59.5 GiB usb usb3: Manufacturer: Linux 6.18.2-edge-sunxi64 ehci_hcd mmcblk0: p1 p2 usb usb3: SerialNumber: 4101000.usb hub 3-0:1.0: USB hub found hub 3-0:1.0: 1 port detected usb usb2: New USB device found, idVendor=1d6b, idProduct=0001, bcdDevice= 6.18 usb usb2: New USB device strings: Mfr=3, Product=2, SerialNumber=1 usb usb2: Product: Generic Platform OHCI controller usb usb2: Manufacturer: Linux 6.18.2-edge-sunxi64 ohci_hcd usb usb2: SerialNumber: 4200400.usb hub 2-0:1.0: USB hub found hub 2-0:1.0: 1 port detected usb usb4: New USB device found, idVendor=1d6b, idProduct=0001, bcdDevice= 6.18 usb usb4: New USB device strings: Mfr=3, Product=2, SerialNumber=1 usb usb4: Product: Generic Platform OHCI controller usb usb4: Manufacturer: Linux 6.18.2-edge-sunxi64 ohci_hcd usb usb4: SerialNumber: 4101400.usb hub 4-0:1.0: USB hub found hub 4-0:1.0: 1 port detected Freeing unused kernel memory: 3584K Run /init as init process usb_phy_generic usb_phy_generic.1.auto: dummy supplies not allowed for exclusive requests (id=vbus) dwmac-sun55i 4510000.ethernet end1: renamed from eth1 dwmac-sun8i 4500000.ethernet end0: renamed from eth0 EXT4-fs (mmcblk0p2): mounted filesystem 2782653c-c693-428c-b157-01071e773e18 ro with writeback data mode. Quota mode: none. Not activating Mandatory Access Control as /sbin/tomoyo-init does not exist. systemd[1]: System time advanced to timestamp on /var/lib/systemd/timesync/clock: Tue 2025-12-30 19:26:57 UTC systemd[1]: systemd 257.9-1~deb13u1 running in system mode (+PAM +AUDIT +SELINUX +APPARMOR +IMA +IPE +SMACK +SECCOMP +GCRYPT -GNUTLS +OPENSSL +ACL +BLKID +CURL +ELFUTILS +FIDO2 +IDN2 -IDN +IPTC +KMOD +LIBCRYPTSETUP +LIBCRYPTSETUP_PLUGINS +LIBFDISK +PCRE2 +PWQUALITY +P11KIT +QRENCODE +TPM2 +BZIP2 +LZ4 +XZ +ZLIB +ZSTD +BPF_FRAMEWORK +BTF -XKBCOMMON -UTMP +SYSVINIT +LIBARCHIVE) systemd[1]: Detected architecture arm64. systemd[1]: Hostname set to <radxa-cubie-a5e>. systemd[1]: bpf-restrict-fs: BPF LSM hook not enabled in the kernel, BPF LSM not supported. systemd[1]: Queued start job for default target graphical.target. systemd[1]: Created slice system-getty.slice - Slice /system/getty. systemd[1]: Created slice system-modprobe.slice - Slice /system/modprobe. systemd[1]: Created slice system-serial\x2dgetty.slice - Slice /system/serial-getty. systemd[1]: Created slice system-systemd\x2dfsck.slice - Slice /system/systemd-fsck. systemd[1]: Created slice user.slice - User and Session Slice. systemd[1]: Started systemd-ask-password-console.path - Dispatch Password Requests to Console Directory Watch. systemd[1]: Started systemd-ask-password-wall.path - Forward Password Requests to Wall Directory Watch. systemd[1]: Set up automount proc-sys-fs-binfmt_misc.automount - Arbitrary Executable File Formats File System Automount Point. systemd[1]: Expecting device dev-disk-by\x2duuid-C2FC\x2d76E8.device - /dev/disk/by-uuid/C2FC-76E8... systemd[1]: Expecting device dev-ttyS0.device - /dev/ttyS0... systemd[1]: Reached target paths.target - Path Units. systemd[1]: Reached target remote-fs.target - Remote File Systems. systemd[1]: Reached target slices.target - Slice Units. systemd[1]: Reached target swap.target - Swaps. systemd[1]: Listening on syslog.socket - Syslog Socket. systemd[1]: Listening on systemd-creds.socket - Credential Encryption/Decryption. systemd[1]: Listening on systemd-initctl.socket - initctl Compatibility Named Pipe. systemd[1]: Listening on systemd-journald-dev-log.socket - Journal Socket (/dev/log). systemd[1]: Listening on systemd-journald.socket - Journal Sockets. systemd[1]: Listening on systemd-networkd.socket - Network Service Netlink Socket. systemd[1]: systemd-pcrextend.socket - TPM PCR Measurements was skipped because of an unmet condition check (ConditionSecurity=measured-uki). systemd[1]: systemd-pcrlock.socket - Make TPM PCR Policy was skipped because of an unmet condition check (ConditionSecurity=measured-uki). systemd[1]: Listening on systemd-udevd-control.socket - udev Control Socket. systemd[1]: Listening on systemd-udevd-kernel.socket - udev Kernel Socket. systemd[1]: dev-hugepages.mount - Huge Pages File System was skipped because of an unmet condition check (ConditionPathExists=/sys/kernel/mm/hugepages). systemd[1]: Mounting dev-mqueue.mount - POSIX Message Queue File System... systemd[1]: Mounting run-lock.mount - Legacy Locks Directory /run/lock... systemd[1]: Mounting sys-kernel-debug.mount - Kernel Debug File System... systemd[1]: sys-kernel-tracing.mount - Kernel Trace File System was skipped because of an unmet condition check (ConditionPathExists=/sys/kernel/tracing). systemd[1]: Starting fake-hwclock-load.service - Restore the current clock... systemd[1]: Starting keyboard-setup.service - Set the console keyboard layout... systemd[1]: Starting kmod-static-nodes.service - Create List of Static Device Nodes... systemd[1]: Starting modprobe@configfs.service - Load Kernel Module configfs... systemd[1]: Starting modprobe@drm.service - Load Kernel Module drm... systemd[1]: Starting modprobe@efi_pstore.service - Load Kernel Module efi_pstore... systemd[1]: Starting modprobe@fuse.service - Load Kernel Module fuse... systemd[1]: netplan-ovs-cleanup.service - OpenVSwitch configuration for cleanup was skipped because of an unmet condition check (ConditionFileIsExecutable=/usr/bin/ovs-vsctl). systemd[1]: systemd-hibernate-clear.service - Clear Stale Hibernate Storage Info was skipped because of an unmet condition check (ConditionPathExists=/sys/firmware/efi/efivars/HibernateLocation-8cf2644b-4b0b-428f-9387-6d876050dc67). systemd[1]: Starting systemd-modules-load.service - Load Kernel Modules... systemd[1]: Starting systemd-network-generator.service - Generate network units from Kernel command line... systemd[1]: systemd-pcrmachine.service - TPM PCR Machine ID Measurement was skipped because of an unmet condition check (ConditionSecurity=measured-uki). systemd[1]: systemd-tpm2-setup-early.service - Early TPM SRK Setup was skipped because of an unmet condition check (ConditionSecurity=measured-uki). fuse: init (API version 7.45) systemd[1]: Starting systemd-udev-load-credentials.service - Load udev Rules from Credentials... systemd[1]: Starting systemd-udev-trigger.service - Coldplug All udev Devices... systemd[1]: Mounted dev-mqueue.mount - POSIX Message Queue File System. systemd[1]: Mounted run-lock.mount - Legacy Locks Directory /run/lock. systemd[1]: Mounted sys-kernel-debug.mount - Kernel Debug File System. systemd[1]: fake-hwclock-load.service: Deactivated successfully. systemd[1]: Finished fake-hwclock-load.service - Restore the current clock. systemd[1]: Finished kmod-static-nodes.service - Create List of Static Device Nodes. systemd[1]: modprobe@configfs.service: Deactivated successfully. systemd[1]: Finished modprobe@configfs.service - Load Kernel Module configfs. systemd[1]: modprobe@drm.service: Deactivated successfully. systemd[1]: Finished modprobe@drm.service - Load Kernel Module drm. systemd[1]: modprobe@efi_pstore.service: Deactivated successfully. Bluetooth: Core ver 2.22 systemd[1]: Finished modprobe@efi_pstore.service - Load Kernel Module efi_pstore. NET: Registered PF_BLUETOOTH protocol family Bluetooth: HCI device and connection manager initialized systemd[1]: modprobe@fuse.service: Deactivated successfully. Bluetooth: HCI socket layer initialized systemd[1]: Finished modprobe@fuse.service - Load Kernel Module fuse. Bluetooth: L2CAP socket layer initialized Bluetooth: SCO socket layer initialized systemd[1]: Finished systemd-network-generator.service - Generate network units from Kernel command line. Bluetooth: HIDP (Human Interface Emulation) ver 1.2 Bluetooth: HIDP socket layer initialized systemd[1]: Finished systemd-udev-load-credentials.service - Load udev Rules from Credentials. Bluetooth: RFCOMM TTY layer initialized systemd[1]: Reached target network-pre.target - Preparation for Network. Bluetooth: RFCOMM socket layer initialized Bluetooth: RFCOMM ver 1.11 systemd[1]: Mounting sys-fs-fuse-connections.mount - FUSE Control File System... Bluetooth: BNEP (Ethernet Emulation) ver 1.3 systemd[1]: Mounting sys-kernel-config.mount - Kernel Configuration File System... Bluetooth: BNEP filters: protocol multicast Bluetooth: BNEP socket layer initialized systemd[1]: systemd-fsck-root.service - File System Check on Root Device was skipped because of an unmet condition check (ConditionPathExists=!/run/initramfs/fsck-root). aic8800_bsp: loading out-of-tree module taints kernel. systemd[1]: Starting systemd-remount-fs.service - Remount Root and Kernel File Systems... -->rfkill_bluetooth_init bluetooth_set_power: start_block=1 bluetooth_set_power: end_block=1 <--rfkill_bluetooth_init systemd[1]: Starting systemd-tmpfiles-setup-dev-early.service - Create Static Device Nodes in /dev gracefully... systemd[1]: Finished systemd-modules-load.service - Load Kernel Modules. systemd[1]: Mounted sys-fs-fuse-connections.mount - FUSE Control File System. systemd[1]: Mounted sys-kernel-config.mount - Kernel Configuration File System. systemd[1]: Starting systemd-sysctl.service - Apply Kernel Variables... EXT4-fs (mmcblk0p2): re-mounted 2782653c-c693-428c-b157-01071e773e18 r/w. systemd[1]: Finished keyboard-setup.service - Set the console keyboard layout. systemd[1]: Finished systemd-remount-fs.service - Remount Root and Kernel File Systems. systemd[1]: systemd-hwdb-update.service - Rebuild Hardware Database was skipped because of an unmet condition check (ConditionNeedsUpdate=/etc). systemd[1]: systemd-pstore.service - Platform Persistent Storage Archival was skipped because of an unmet condition check (ConditionDirectoryNotEmpty=/sys/fs/pstore). systemd[1]: Starting systemd-random-seed.service - Load/Save OS Random Seed... systemd[1]: systemd-tpm2-setup.service - TPM SRK Setup was skipped because of an unmet condition check (ConditionSecurity=measured-uki). systemd[1]: Finished systemd-tmpfiles-setup-dev-early.service - Create Static Device Nodes in /dev gracefully. systemd[1]: Finished systemd-sysctl.service - Apply Kernel Variables. systemd[1]: systemd-sysusers.service - Create System Users was skipped because no trigger condition checks were met. systemd[1]: Starting systemd-resolved.service - Network Name Resolution... systemd[1]: Starting systemd-timesyncd.service - Network Time Synchronization... systemd[1]: Starting systemd-tmpfiles-setup-dev.service - Create Static Device Nodes in /dev... systemd[1]: Finished systemd-tmpfiles-setup-dev.service - Create Static Device Nodes in /dev. systemd[1]: Reached target local-fs-pre.target - Preparation for Local File Systems. systemd[1]: Starting systemd-udevd.service - Rule-based Manager for Device Events and Files... systemd[1]: Started systemd-timesyncd.service - Network Time Synchronization. systemd[1]: Reached target time-set.target - System Time Set. systemd[1]: Finished systemd-udev-trigger.service - Coldplug All udev Devices. systemd[1]: Mounting tmp.mount - /tmp... systemd[1]: Started systemd-udevd.service - Rule-based Manager for Device Events and Files. systemd[1]: Starting systemd-networkd.service - Network Configuration... systemd[1]: Mounted tmp.mount - /tmp. systemd[1]: Listening on systemd-rfkill.socket - Load/Save RF Kill Switch Status /dev/rfkill Watch. systemd[1]: Starting systemd-rfkill.service - Load/Save RF Kill Switch Status... random: crng init done systemd[1]: Found device dev-ttyS0.device - /dev/ttyS0. systemd[1]: Finished systemd-random-seed.service - Load/Save OS Random Seed. systemd[1]: first-boot-complete.target - First Boot Complete was skipped because of an unmet condition check (ConditionFirstBoot=yes). bluetooth_set_power: start_block=1 bluetooth_set_power: end_block=1 systemd[1]: Started systemd-rfkill.service - Load/Save RF Kill Switch Status. systemd[1]: Reached target usb-gadget.target - Hardware activated USB gadget. panfrost 1800000.gpu: clock rate = 432000000 panfrost 1800000.gpu: bus_clock rate = 200000000 panfrost 1800000.gpu: mali-g57 id 0x9091 major 0x0 minor 0x1 status 0x0 panfrost 1800000.gpu: features: 00000000,000019f7, issues: 00000001,80000400 panfrost 1800000.gpu: Features: L2:0x07110206 Shader:0x00000000 Tiler:0x00000809 Mem:0x1 MMU:0x00002830 AS:0xff JS:0x7 panfrost 1800000.gpu: shader_present=0x1 l2_present=0x1 systemd[1]: Started systemd-resolved.service - Network Name Resolution. [drm] Initialized panfrost 1.4.0 for 1800000.gpu on minor 0 systemd[1]: Reached target nss-lookup.target - Host and Network Name Lookups. cfg80211: Loading compiled-in X.509 certificates for regulatory database Loaded X.509 cert 'sforshee: 00b28ddf47aef9cea7' Loaded X.509 cert 'wens: 61c038651aabdcf94bd0ac7ff06c7248db18c600' systemd[1]: Found device dev-disk-by\x2duuid-C2FC\x2d76E8.device - /dev/disk/by-uuid/C2FC-76E8. systemd[1]: Starting systemd-fsck@dev-disk-by\x2duuid-C2FC\x2d76E8.service - File System Check on /dev/disk/by-uuid/C2FC-76E8... systemd[1]: Started systemd-networkd.service - Network Configuration. systemd[1]: Starting systemd-networkd-persistent-storage.service - Enable Persistent Storage in systemd-networkd... dwmac-sun55i 4510000.ethernet end1: Register MEM_TYPE_PAGE_POOL RxQ-0 dwmac-sun55i 4510000.ethernet end1: PHY [stmmac-1:01] driver [Generic PHY] (irq=POLL) sunxi-mmc 4021000.mmc: data error, sending stop command aicbsp: sdio_err:<aicwf_sdio_tx_msg,996>: aicwf_sdio_send_pkt fail-110 dwmac4: Master AXI performs fixed burst length aicbsp: sdio_err:<aicwf_sdio_bus_txmsg,1140>: send faild:0, 0,4de dwmac-sun55i 4510000.ethernet end1: No Safety Features support found dwmac-sun55i 4510000.ethernet end1: IEEE 1588-2008 Advanced Timestamp supported dwmac-sun55i 4510000.ethernet end1: registered PTP clock dwmac-sun55i 4510000.ethernet end1: configuring for phy/rgmii-id link mode 8021q: adding VLAN 0 to HW filter on device end1 dwmac-sun8i 4500000.ethernet end0: Register MEM_TYPE_PAGE_POOL RxQ-0 dwmac-sun8i 4500000.ethernet end0: PHY [stmmac-0:01] driver [Generic PHY] (irq=POLL) dwmac-sun8i 4500000.ethernet end0: No Safety Features support found dwmac-sun8i 4500000.ethernet end0: No MAC Management Counters available dwmac-sun8i 4500000.ethernet end0: PTP not supported by HW dwmac-sun8i 4500000.ethernet end0: configuring for phy/rgmii-id link mode systemd[1]: Finished systemd-networkd-persistent-storage.service - Enable Persistent Storage in systemd-networkd. systemd[1]: Finished systemd-fsck@dev-disk-by\x2duuid-C2FC\x2d76E8.service - File System Check on /dev/disk/by-uuid/C2FC-76E8. systemd[1]: Mounting boot.mount - /boot... systemd[1]: Mounted boot.mount - /boot. systemd[1]: Reached target local-fs.target - Local File Systems. systemd[1]: Listening on systemd-sysext.socket - System Extension Image Management. systemd[1]: Starting armbian-zram-config.service - Armbian ZRAM config... systemd[1]: Starting console-setup.service - Set console font and keymap... systemd[1]: Starting systemd-binfmt.service - Set Up Additional Binary Formats... systemd[1]: systemd-machine-id-commit.service - Save Transient machine-id to Disk was skipped because of an unmet condition check (ConditionPathIsMountPoint=/etc/machine-id). systemd[1]: Finished console-setup.service - Set console font and keymap. systemd[1]: proc-sys-fs-binfmt_misc.automount: Got automount request for /proc/sys/fs/binfmt_misc, triggered by 328 (systemd-binfmt) systemd[1]: Mounting proc-sys-fs-binfmt_misc.mount - Arbitrary Executable File Formats File System... systemd[1]: Mounted proc-sys-fs-binfmt_misc.mount - Arbitrary Executable File Formats File System. systemd[1]: Finished systemd-binfmt.service - Set Up Additional Binary Formats. zram: Added device: zram0 zram: Added device: zram1 zram: Added device: zram2 zram0: detected capacity change from 0 to 2025816 Adding 1012904k swap on /dev/zram0. Priority:5 extents:1 across:1012904k SS zram1: detected capacity change from 0 to 102400 systemd[1]: Finished armbian-zram-config.service - Armbian ZRAM config. systemd[1]: Starting armbian-ramlog.service - Armbian memory supported logging... EXT4-fs (zram1): mounted filesystem 81b9ded1-bf3b-46ee-bb7f-bf31de2b5cdc r/w without journal. Quota mode: none. systemd[1]: Finished armbian-ramlog.service - Armbian memory supported logging. systemd[1]: Starting systemd-journald.service - Journal Service... systemd-journald[416]: Collecting audit messages is disabled. systemd[1]: Started systemd-journald.service - Journal Service. systemd-journald[416]: Received client request to flush runtime journal. ---- Closed the serial port /dev/tty.PL2303G-USBtoUART8430 ----

NanoPi R76S is supposed to have PHC hardware timestamp support with both ethernet interfaces. Unfortunately ethtool -T returns no hardware support. Would be great if PHC could be enabled in this nice box.

It depends on how you have bricked it. Reflashing Android takes you back to a clean starting point.

Hello - Very new to this all and trying to learn my way around. I have an OPi4a which I was previously using for octoprint, etc. Was able to get it going using OrangePi's provided Ubuntu22.04 Jammy image, but am needing to reconfigure and was interested in armbian as the official images from OrangePi can be hard to access at times (site seems to intermittently go down / time out?), and from what I've seen there's very limited support from the manufacturer. Anyways - for the uninitiated, what is the status of the image for the 4a? Seeing the most recent post - does the backport being merged mean that it is possible to build from armbian main? Which target board should be selected? I am not seeing an option for the 4a, or any with the T527 chip. Alternatively, the most recent image I'm seeing is from @JuanEsf - to get this to work do I just need to use something like balena and flash from URL? Very new to all this, any help is appreciated.

The x96q-v5-1 image support aic8800 wifi chip without modify anything from dtb. Follow this https://github.com/LYU4662/aic8800-sdio-linux-1.0, the AIC8800 and alternate based on AIC8800 will work!

Alright, found something. @Meestor_X please try this one: https://testing.armbian.de/Armbian-unofficial_26.02.0-trunk_Radxa-cubie-a5e_trixie_edge_6.18.2_minimal.img.xz

Well, at this point, hard to say what's going on: I'm not sure what happened during my chroot sessions but it looks like / in now non crypted and the boot options were completely overridden by who know's what verbosity=1 bootlogo=false console=both extraargs=cma=256M overlay_prefix=rockchip-rk3588 fdtfile=rockchip/rk3588-rock-5-itx.dtb rootdev=UUID=92f542d4-5a03-424e-b953-e711111186dc rootfstype=ext4 usbstoragequirks=0x2537:0x1066:u,0x2537:0x1068:u And I can boot without having to luks decrypt. It is probably a side effect of what I mounted in the chroot (/run /sys, etc) but I did not know this was even possible and I would be interested in theories or possible explanations. Thanks to all of you, especially @IBV

Will you please give the detail step?I flash "Armbian 25.11.2 trixie" ,but I can't find any useful dtbo file.

--> (667) DEBUG: Partition table after write_uboot [ /dev/loop0 ] --> (667) COMMAND: sfdisk -l /dev/loop0 The primary GPT table is corrupt, but the backup appears OK, so that will be used. Disk /dev/loop0: 2.37 GiB, 2541748224 bytes, 4964352 sectors Units: sectors of 1 * 512 = 512 bytes Sector size (logical/physical): 512 bytes / 512 bytes I/O size (minimum/optimal): 512 bytes / 512 bytes Disklabel type: gpt Disk identifier: 62C4432A-F158-49BE-8F59-F5A5895C7057 Device Start End Sectors Size Type /dev/loop0p1 8192 1056767 1048576 512M Linux extended boot /dev/loop0p2 1056768 4962303 3905536 1.9G Linux root (ARM-64) This is what the image looks while still on loop dev just before detaching from. But for some reason its messed up right after. Don't know why...yet root@build:~/build/output/images# parted Armbian-unofficial_26.02.0-trunk_Radxa-cubie-a5e_trixie_edge_6.18.2_minimal.img u b p Error: /root/build/output/images/Armbian-unofficial_26.02.0-trunk_Radxa-cubie-a5e_trixie_edge_6.18.2_minimal.img: unrecognised disk label Model: (file) Disk /root/build/output/images/Armbian-unofficial_26.02.0-trunk_Radxa-cubie-a5e_trixie_edge_6.18.2_minimal.img: 2541748224B Sector size (logical/physical): 512B/512B Partition Table: unknown Disk Flags:

How can you active spi support?I burn " 25.11.2" image,but I can't find any overlay of spi ,uart or i2c. This is my system status: cat /etc/os-release PRETTY_NAME="Armbian 25.11.2 trixie" NAME="Debian GNU/Linux" VERSION_ID="13" VERSION="13 (trixie)" VERSION_CODENAME=trixie DEBIAN_VERSION_FULL=13.2 ID=debian HOME_URL="https://www.armbian.com" SUPPORT_URL="https://forum.armbian.com" BUG_REPORT_URL="https://www.armbian.com/bugs" ARMBIAN_PRETTY_NAME="Armbian 25.11.2 trixie" uname -a Linux Pi-s 6.12.58-current-rockchip64 #3 SMP PREEMPT Thu Nov 13 20:34:41 UTC 2025 aarch64 GNU/Linux ls /boot/dtb/rockchip/overlay/rk3308* /boot/dtb/rockchip/overlay/rk3308-b@1.3ghz.dtbo /boot/dtb/rockchip/overlay/rk3308-otg-host.dtbo /boot/dtb/rockchip/overlay/rk3308-bs@1.3ghz.dtbo /boot/dtb/rockchip/overlay/rk3308-s0-ext-antenna.dtbo /boot/dtb/rockchip/overlay/rk3308-bs.dtbo

This is way too much work. Basically I just came here to say that prebuilt images of trunk 100 work, 130 and 150 don't. So... Just a PSA to let people know that they likely won't be able to use those prebuilt images. It's probably moot anyway as I expect there aren't any changes that fix the main issues.

There is a separate boot partiton, it should be there. MACOS same as Windows might hide/block it as it is tagged as not normal filesystem (0x8300) but boot related (0xea00 or 0xef00) Linux has no issue with it.

Found the method. A program called anylinuxfs will mount the EXT4 sd card on a Mac. However, even on the Trunk 100, I don't see armbianEnv.txt in /boot. Where do I find it?

You could use the Cubie for it. The trunk.100 works you said, so you have a working Linux computer, can be operated via serial cable console.

I usually just re-plug the sdcard back into my laptop, the fs mounts automatically for me. Using Linux though, no clue about MacOS.

I didn't know it was possible to edit a file within a boot image... I'm using MacOS, how would I do that?

Fair enough. "WRITE the image" would probably be clearer. The image file is from the repository, I'm using Balena to WRITE the image (rather than MAKE) to the SD card. I'm sure you knew what I meant, but I agree that clarity is important. BTW - Where would I find the changelogs for these trunks?


moved to tvboxes

---- Opened the serial port /dev/tty.PL2303G-USBtoUART8430 ---- U-Boot SPL 2026.01-rc4_armbian-2026.01-rc4-S0e0a-Peafc-H5aa4-Vd0f6-B4d1d-R448a (Dec 29 2025 - 03:26:30 +0000) DRAM: 2048 MiB Trying to boot from MMC1 NOTICE: BL31: v2.12.0(debug):armbian NOTICE: BL31: Built : 03:26:10, Dec 29 2025 NOTICE: BL31: Detected Allwinner A523 SoC (1890) NOTICE: BL31: Found U-Boot DTB at 0xa0ab9f8, model: Radxa Cubie A5E INFO: GICv3 without legacy support detected. INFO: ARM GICv3 driver initialized in EL3 INFO: Maximum SPI INTID supported: 287 INFO: Configuring SPC Controller INFO: BL31: Platform setup done INFO: BL31: Initializing runtime services INFO: BL31: cortex_a55: CPU workaround for erratum 1530923 was applied INFO: PSCI: Suspend is unavailable INFO: BL31: Preparing for EL3 exit to normal world INFO: Entry point address = 0x4a000000 INFO: SPSR = 0x3c9 ns16550_serial serial@2500000: pinctrl_select_state_full: uclass_get_device_by_phandle_id: err=-19 U-Boot 2026.01-rc4_armbian-2026.01-rc4-S0e0a-Peafc-H5aa4-Vd0f6-B4d1d-R448a (Dec 29 2025 - 03:26:30 +0000) Allwinner Technology CPU: Allwinner A523 (SUN55I) Model: Radxa Cubie A5E DRAM: 2 GiB sunxi_set_gate: (CLK#35) unhandled Core: 77 devices, 22 uclasses, devicetree: separate WDT: Not starting watchdog@2050000 MMC: mmc@4020000: 0 Loading Environment from FAT... Unable to read "uboot.env" from mmc0:1... In: serial@2500000 Out: serial@2500000 Err: serial@2500000 Net: eth0: ethernet@4500000 starting USB... sun4i_usb_phy phy@4100400: External vbus detected, not enabling our own vbus USB EHCI 1.00 USB OHCI 1.0 USB EHCI 1.00 USB OHCI 1.0 Bus usb@4101000: 1 USB Device(s) found Bus usb@4101400: 1 USB Device(s) found Bus usb@4200000: 1 USB Device(s) found Bus usb@4200400: 1 USB Device(s) found scanning usb for storage devices... 0 Storage Device(s) found Hit any key to stop autoboot: 0 switch to partitions #0, OK mmc0 is current device Scanning mmc 0:1... Found U-Boot script /boot.scr 4641 bytes read in 3 ms (1.5 MiB/s) ## Executing script at 4fc00000 U-boot loaded from SD Boot script loaded from mmc 190 bytes read in 2 ms (92.8 KiB/s) The file sun55i-a527-radxa-a5e.dtb was not found in the path /dtb/allwinner Load fdt: /dtb/allwinner/sun55i-a527-cubie-a5e.dtb 33947 bytes read in 6 ms (5.4 MiB/s) Working FDT set to 4fa00000 Failed to load '/dtb/overlay/sun55i-a527-fixup.scr' 15452067 bytes read in 642 ms (23 MiB/s) 31721984 bytes read in 1315 ms (23 MiB/s) Moving Image from 0x40080000 to 0x40200000, end=0x42130000 ## Loading init Ramdisk from Legacy Image at 4ff00000 ... Image Name: uInitrd Image Type: AArch64 Linux RAMDisk Image (gzip compressed) Data Size: 15452003 Bytes = 14.7 MiB Load Address: 00000000 Entry Point: 00000000 Verifying Checksum ... OK ## Flattened Device Tree blob at 4fa00000 Booting using the fdt blob at 0x4fa00000 Working FDT set to 4fa00000 Loading Ramdisk to 49143000, end 49fff763 ... OK Loading Device Tree to 00000000490d2000, end 0000000049142fff ... OK Working FDT set to 490d2000 Starting kernel ... Never goes any further. It doesn't get an IP so I can't SSH into it. The "heatbeat" LED does keep flashing, though... Comparing a the trunk 100 which DOES go on to the login prompt and finishes normally: ---- Opened the serial port /dev/tty.PL2303G-USBtoUART8430 ---- U-Boot SPL 2026.01-rc4_armbian-2026.01-rc4-Sd24f-P0000-He0b4-V52aa-Bbf55-R448a (Dec 19 2025 - 03:11:57 +0000) DRAM: 2048 MiB Trying to boot from MMC1 NOTICE: BL31: v2.12.0(debug):armbian NOTICE: BL31: Built : 03:11:45, Dec 19 2025 NOTICE: BL31: Detected Allwinner A523 SoC (1890) NOTICE: BL31: Found U-Boot DTB at 0xa0ab9f8, model: Radxa Cubie A5E INFO: GICv3 without legacy support detected. INFO: ARM GICv3 driver initialized in EL3 INFO: Maximum SPI INTID supported: 287 INFO: Configuring SPC Controller INFO: BL31: Platform setup done INFO: BL31: Initializing runtime services INFO: BL31: cortex_a55: CPU workaround for erratum 1530923 was applied INFO: PSCI: Suspend is unavailable INFO: BL31: Preparing for EL3 exit to normal world INFO: Entry point address = 0x4a000000 INFO: SPSR = 0x3c9 ns16550_serial serial@2500000: pinctrl_select_state_full: uclass_get_device_by_phandle_id: err=-19 U-Boot 2026.01-rc4_armbian-2026.01-rc4-Sd24f-P0000-He0b4-V52aa-Bbf55-R448a (Dec 19 2025 - 03:11:57 +0000) Allwinner Technology CPU: Allwinner A523 (SUN55I) Model: Radxa Cubie A5E DRAM: 2 GiB sunxi_set_gate: (CLK#35) unhandled Core: 77 devices, 22 uclasses, devicetree: separate WDT: Not starting watchdog@2050000 MMC: mmc@4020000: 0 Loading Environment from FAT... Unable to read "uboot.env" from mmc0:1... In: serial@2500000 Out: serial@2500000 Err: serial@2500000 Net: eth0: ethernet@4500000 starting USB... sun4i_usb_phy phy@4100400: External vbus detected, not enabling our own vbus USB EHCI 1.00 USB OHCI 1.0 USB EHCI 1.00 USB OHCI 1.0 Bus usb@4101000: 1 USB Device(s) found Bus usb@4101400: 1 USB Device(s) found Bus usb@4200000: 1 USB Device(s) found Bus usb@4200400: 1 USB Device(s) found scanning usb for storage devices... 0 Storage Device(s) found Hit any key to stop autoboot: 0 switch to partitions #0, OK mmc0 is current device Scanning mmc 0:1... Found U-Boot script /boot.scr 4641 bytes read in 2 ms (2.2 MiB/s) ## Executing script at 4fc00000 U-boot loaded from SD Boot script loaded from mmc 190 bytes read in 1 ms (185.5 KiB/s) The file sun55i-a527-radxa-a5e.dtb was not found in the path /dtb/allwinner Load fdt: /dtb/allwinner/sun55i-a527-cubie-a5e.dtb 17944 bytes read in 4 ms (4.3 MiB/s) Working FDT set to 4fa00000 Failed to load '/dtb/overlay/sun55i-a527-fixup.scr' 14716909 bytes read in 834 ms (16.8 MiB/s) 31918592 bytes read in 1323 ms (23 MiB/s) Moving Image from 0x40080000 to 0x40200000, end=0x42150000 ## Loading init Ramdisk from Legacy Image at 4ff00000 ... Image Name: uInitrd Image Type: AArch64 Linux RAMDisk Image (gzip compressed) Data Size: 14716845 Bytes = 14 MiB Load Address: 00000000 Entry Point: 00000000 Verifying Checksum ... OK ## Flattened Device Tree blob at 4fa00000 Booting using the fdt blob at 0x4fa00000 Working FDT set to 4fa00000 Loading Ramdisk to 491f7000, end 49ffffad ... OK Loading Device Tree to 000000004918a000, end 00000000491f6fff ... OK Working FDT set to 4918a000 Starting kernel ... Very little is different, except that the ftd is about twice the size...

Post the UART log.

Hello. I recently got a vontar-dq08 working with armbian. I used someone's build for a x88pro, so I replaced the dtb with the one that came on my board. After editing the ArmbianEnv.txt and resetting, it did not boot. Idk if it's a typo on my end or the tree not working, but to make it boot I would just have to change ArmbianEnv.txt, but taking the sdcard out and plugging it in my computer I can't find the file in /boot How can I revert the ArmbianEnv.txt when my machine doesn't boot?

Succes, I lowlevel formatted my SD cart. Now i can install the CLI I think there was something not right The next thing to try is install a desktop image. And fix the overscan issue and then install to the emmc internal memory My internal menory is Sandisk SDINADF4-16G so i am hopefull. But when i brick the system, is it stil possible to boot from a SD card or must i try to flash a version of android first using a USB A to USB a cabble? Sorry I am not allowed to upload Image?
